构建坚不可摧的AI系统：全链路故障注入测试实战指南

引言：为什么AI系统更需要容错测试？

在当今数字化时代，AI系统已从实验室走向生产环境，承担着推荐算法、风险控制、智能客服等关键业务功能。与传统软件系统不同，AI系统面临双重复杂性：既有传统分布式系统的架构复杂性，又增加了机器学习特有的不确定性。一次模型推理失败、一次数据管道异常，都可能导致连锁反应，影响用户体验甚至造成业务损失。

本文将通过实战化视角，深入探讨AI系统的容错测试方法论，结合具体代码示例和架构图解，帮助您构建真正可靠的智能系统。

1. 容错测试核心目标：定义AI系统的韧性标准

1.1 三大核心验证维度

可用性是AI系统的生命线。以推荐系统为例，99.9%的可用性意味着每年只能有约8.76小时的服务中断。但单纯追求高可用数字是不够的，我们需要区分：

• 完全可用：所有功能正常，推荐准确率100%
• 降级可用：核心推荐功能正常，但个性化程度降低
• 基本可用：返回通用推荐结果，保证页面不报错

一致性在AI系统中尤为重要。考虑这样一个场景：用户连续请求同一个推荐服务，第一次返回了商品A、B、C，第二次由于缓存故障，返回了商品D、E、F。这种不一致会严重影响用户体验和业务转化。

恢复能力包含三个关键指标：

1. MTTD（平均故障检测时间）：系统多快能发现故障
2. MTTR（平均修复时间）：系统多快能自动恢复
3. 恢复完整性：恢复后数据是否完整、状态是否一致

1.2 AI系统的特殊容错挑战

与传统的Web服务不同，AI系统面临独特的挑战：

1. 模型推理的不确定性：相同的输入可能产生不同的输出（特别是在概率性模型中）
2. 数据依赖的复杂性：特征工程、数据预处理的多层依赖
3. 资源消耗的突发性：GPU显存溢出、推理时间波动
4. 第三方服务耦合：模型服务、特征存储、向量数据库等多组件依赖

2. 硬件故障测试：从基础资源到基础设施

2.1 GPU/CPU故障模拟与应对

GPU故障是AI系统特有的痛点。以下Python代码展示了如何模拟和应对GPU显存不足：

import torch
import numpy as np
from contextlib import contextmanager
import threading
import time

class GPUStressTest:
    """GPU压力测试与容错验证"""

    def __init__(self, reserve_mb=200):
        """
        初始化GPU测试器
        :param reserve_mb: 预留显存大小(MB)，用于系统运行
        """
        self.reserve_bytes = reserve_mb * 1024 * 1024

    @contextmanager
    def simulate_gpu_oom(self):
        """
        模拟GPU显存不足的上下文管理器
        使用场景：with test.simulate_gpu_oom():
                     model.predict(data)
        """
        if torch.cuda.is_available():
            # 获取GPU总显存和已使用显存
            total_memory = torch.cuda.get_device_properties(0).total_memory
            used_memory = torch.cuda.memory_allocated(0)

            # 计算可用显存
            available_memory = total_memory - used_memory - self.reserve_bytes

            if available_memory > 0:
                # 故意分配大量显存，制造OOM场景
                try:
                    # 创建大张量占用显存
                    block_size = min(available_memory, 100 * 1024 * 1024)  # 每次分配100MB
                    blocks = []
                    allocated = 0

                    while allocated < available_memory:
                        try:
                            block = torch.empty(
                                block_size // 4,  # float32占4字节
                                dtype=torch.float32,
                                device='cuda'
                            )
                            blocks.append(block)
                            allocated += block_size
                        except RuntimeError as e:
                            if "out of memory" in str(e):
                                print(f"成功模拟OOM，已分配{allocated/(1024*1024):.1f}MB")
                                break
                    yield
                finally:
                    # 清理分配的显存
                    del blocks
                    torch.cuda.empty_cache()
            else:
                yield
        else:
            print("未检测到GPU，跳过OOM测试")
            yield

    def test_model_oom_resilience(self, model, input_data):
        """
        测试模型在OOM情况下的降级策略
        """
        print("开始OOM容错测试...")

        try:
            with self.simulate_gpu_oom():
                # 尝试在OOM环境下推理
                result = model.predict(input_data)
                print("警告：模型在OOM情况下仍成功推理，可能需要调整测试参数")
                return result
        except RuntimeError as e:
            if "out of memory" in str(e):
                print("检测到OOM异常，触发降级策略")
                # 触发降级策略
                return self._fallback_prediction(input_data)
            else:
                raise e

    def _fallback_prediction(self, input_data):
        """
        OOM降级策略：使用轻量级模型或返回默认结果
        """
        print("执行降级预测策略")
        # 1. 尝试使用CPU推理
        # 2. 返回缓存的通用结果
        # 3. 使用简化模型
        return {"prediction": "default", "reason": "gpu_oom_fallback"}

class CPUStressTest:
    """CPU资源耗尽测试"""

    def simulate_cpu_stress(self, duration=30, threads_per_core=2):
        """
        模拟CPU使用率100%场景
        """
        import multiprocessing
        import math

        def cpu_burn():
            """CPU密集型计算"""
            while True:
                # 计算质数，消耗CPU
                for i in range(2, 10000):
                    for j in range(2, int(math.sqrt(i)) + 1):
                        if i % j == 0:
                            break

        # 创建多个进程消耗CPU
        num_cores = multiprocessing.cpu_count()
        processes = []

        print(f"开始CPU压力测试，使用{num_cores * threads_per_core}个线程")

        for _ in range(num_cores * threads_per_core):
            p = multiprocessing.Process(target=cpu_burn)
            p.start()
            processes.append(p)

        # 等待指定时间
        time.sleep(duration)

        # 清理进程
        for p in processes:
            p.terminate()
            p.join()

        print("CPU压力测试结束")

# 使用示例
def test_hardware_resilience():
    """硬件容错测试入口"""

    # 1. GPU OOM测试
    gpu_tester = GPUStressTest(reserve_mb=500)

    # 模拟AI模型
    class AIModel:
        def predict(self, data):
            # 模拟模型推理
            if torch.cuda.is_available():
                # 尝试分配显存
                tensor = torch.randn(10000, 10000, device='cuda')
                return tensor.mean().item()
            return 0.5

    model = AIModel()
    gpu_tester.test_model_oom_resilience(model, "test_data")

    # 2. CPU压力测试
    cpu_tester = CPUStressTest()
    # 谨慎使用：cpu_tester.simulate_cpu_stress(duration=10)

关键发现：在GPU OOM测试中，我们发现多数深度学习框架（PyTorch、TensorFlow）的默认行为是直接抛出异常，这可能导致整个服务崩溃。合理的容错策略应包括：

1. 分层降级：GPU → CPU → 简化模型 → 缓存结果
2. 资源预检：推理前检查可用显存
3. 批处理调整：动态调整batch size

2.2 存储故障测试实战

存储故障往往是最具破坏性的。以下Java代码展示了磁盘故障的模拟：

import java.io.*;
import java.nio.file.*;
import java.util.concurrent.atomic.AtomicBoolean;

public class StorageFailureTest {

    /**
     * 模拟磁盘写满场景
     */
    public static void simulateDiskFull(String targetPath, long reserveMB)
            throws IOException, InterruptedException {

        File targetDir = new File(targetPath);
        if (!targetDir.exists()) {
            targetDir.mkdirs();
        }

        // 获取磁盘空间信息
        FileStore store = Files.getFileStore(targetDir.toPath());
        long totalSpace = store.getTotalSpace();
        long usableSpace = store.getUsableSpace();
        long threshold = reserveMB * 1024 * 1024;

        System.out.printf("磁盘信息：总量=%.2fGB, 可用=%.2fGB, 保留=%.2fGB%n",
                totalSpace / (1024.0 * 1024 * 1024),
                usableSpace / (1024.0 * 1024 * 1024),
                threshold / (1024.0 * 1024 * 1024));

        // 如果可用空间大于保留空间，则填充磁盘
        if (usableSpace > threshold) {
            long bytesToFill = usableSpace - threshold;
            System.out.printf("将填充 %.2fGB 数据%n",
                    bytesToFill / (1024.0 * 1024 * 1024));

            AtomicBoolean stopFlag = new AtomicBoolean(false);

            // 监控线程：当可用空间接近阈值时停止
            Thread monitorThread = new Thread(() -> {
                try {
                    while (!stopFlag.get()) {
                        long currentUsable = Files.getFileStore(
                            targetDir.toPath()).getUsableSpace();
                        if (currentUsable <= threshold * 1.1) { // 10%缓冲
                            stopFlag.set(true);
                            System.out.println("磁盘空间已接近阈值，停止填充");
                            break;
                        }
                        Thread.sleep(1000);
                    }
                } catch (Exception e) {
                    e.printStackTrace();
                }
            });

            monitorThread.start();

            // 填充线程
            Thread fillThread = new Thread(() -> {
                long filled = 0;
                int fileIndex = 0;

                while (!stopFlag.get() && filled < bytesToFill) {
                    String fileName = targetPath + "/fill_" + fileIndex + ".dat";
                    File file = new File(fileName);

                    try (FileOutputStream fos = new FileOutputStream(file)) {
                        // 每次写入10MB
                        byte[] buffer = new byte[10 * 1024 * 1024];
                        fos.write(buffer);
                        filled += buffer.length;
                        fileIndex++;

                        if (fileIndex % 10 == 0) {
                            System.out.printf("已填充 %.2fGB/% .2fGB%n",
                                    filled / (1024.0 * 1024 * 1024),
                                    bytesToFill / (1024.0 * 1024 * 1024));
                        }
                    } catch (IOException e) {
                        if (e.getMessage().contains("No space left")) {
                            System.out.println("磁盘已满，无法继续写入");
                            stopFlag.set(true);
                            break;
                        }
                    }
                }
            });

            fillThread.start();
            fillThread.join();
            monitorThread.join();

            System.out.println("磁盘填充完成，开始测试系统行为...");
        } else {
            System.out.println("磁盘空间已不足，直接进行测试");
        }

        // 测试系统在磁盘满的情况下的行为
        testSystemBehaviorUnderDiskFull(targetPath);
    }

    /**
     * 测试磁盘满时系统的容错行为
     */
    private static void testSystemBehaviorUnderDiskFull(String testPath) {
        System.out.println("\n=== 磁盘满容错测试 ===");

        // 测试1: 日志写入
        testLogging(testPath);

        // 测试2: 模型保存
        testModelPersistence(testPath);

        // 测试3: 临时文件创建
        testTempFileCreation(testPath);
    }

    private static void testLogging(String path) {
        System.out.println("测试日志系统...");
        try {
            File logFile = new File(path, "system.log");
            FileWriter writer = new FileWriter(logFile, true);
            writer.write("测试日志条目\n");
            writer.flush();
            writer.close();
            System.out.println("✓ 日志写入成功");
        } catch (IOException e) {
            System.out.println("✗ 日志写入失败: " + e.getMessage());

            // 验证降级策略：是否回退到系统日志或控制台
            System.err.println("降级日志: 测试条目 - " + new java.util.Date());
        }
    }

    private static void testModelPersistence(String path) {
        System.out.println("测试模型持久化...");
        // 模拟模型保存逻辑
        File modelFile = new File(path, "latest_model.pt");

        try {
            // 尝试保存模型
            byte[] mockModelData = new byte[1024 * 1024]; // 1MB模拟数据
            Files.write(modelFile.toPath(), mockModelData,
                       StandardOpenOption.CREATE,
                       StandardOpenOption.TRUNCATE_EXISTING);
            System.out.println("✓ 模型保存成功");
        } catch (IOException e) {
            System.out.println("✗ 模型保存失败: " + e.getMessage());

            // 验证容错策略
            if (e.getMessage().contains("No space")) {
                System.out.println("触发模型保存降级策略:");
                System.out.println("1. 尝试清理旧模型缓存");
                System.out.println("2. 压缩模型保存");
                System.out.println("3. 保存到备用位置");
            }
        }
    }

    /**
     * PVC挂载失败测试
     */
    public static void testPVCFailure() {
        System.out.println("\n=== PVC挂载失败测试 ===");

        // 模拟K8s PVC挂载失败场景
        String[] mountPoints = {"/data/model", "/data/logs", "/data/cache"};

        for (String mountPoint : mountPoints) {
            File mountDir = new File(mountPoint);

            if (!mountDir.exists()) {
                System.out.printf("PVC挂载点 %s 不存在%n", mountPoint);

                // 测试系统行为
                if (mountPoint.contains("model")) {
                    System.out.println("模型存储不可用，触发降级:");
                    System.out.println("1. 使用内置默认模型");
                    System.out.println("2. 从备用URL下载模型");
                } else if (mountPoint.contains("logs")) {
                    System.out.println("日志存储不可用:");
                    System.out.println("1. 写入临时目录");
                    System.out.println("2. 增加日志缓冲");
                }
            } else {
                // 测试写权限
                File testFile = new File(mountDir, "test_write.tmp");
                try {
                    testFile.createNewFile();
                    testFile.delete();
                    System.out.printf("✓ PVC挂载点 %s 正常%n", mountPoint);
                } catch (IOException e) {
                    System.out.printf("✗ PVC挂载点 %s 写入失败: %s%n",
                            mountPoint, e.getMessage());
                }
            }
        }
    }

    // 清理方法
    public static void cleanup(String path) throws IOException {
        File dir = new File(path);
        if (dir.exists() && dir.isDirectory()) {
            Files.walk(dir.toPath())
                 .sorted(java.util.Comparator.reverseOrder())
                 .map(Path::toFile)
                 .forEach(File::delete);
            System.out.println("测试数据清理完成");
        }
    }
}

2.3 网络故障模拟：Chaos Mesh实战

网络分区、延迟、丢包是微服务架构的常见问题。Chaos Mesh提供了强大的网络故障注入能力：

# network-chaos.yaml
apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: ai-system-network-test
  namespace: ai-production
spec:
  action: partition  # 网络分区
  mode: all
  selector:
    namespaces:
      - ai-production
    labelSelectors:
      "app": "recommendation-service"
  direction: both
  loss:
    loss: "100%"  # 100%丢包，模拟网络断开
    correlation: "100"
  duration: "5m"  # 持续5分钟

Python集成示例：

import time
import requests
from chaosmesh.experiments.network import NetworkChaos
from chaosmesh.k8s.chaos import ChaosExperiment

class AINetworkResilienceTest:
    """AI系统网络容错测试"""

    def __init__(self, k8s_config=None):
        self.chaos_experiment = ChaosExperiment(k8s_config)

    def test_network_partition(self, service_name, duration_min=5):
        """
        测试网络分区下的服务容错
        """
        print(f"开始网络分区测试，目标服务: {service_name}")

        # 1. 创建网络分区
        network_chaos = NetworkChaos(
            name=f"network-partition-{service_name}",
            namespace="ai-production",
            action="partition",
            selector={
                "labelSelectors": {
                    "app": service_name
                }
            },
            direction="both",
            duration=f"{duration_min}m"
        )

        # 2. 应用网络故障
        experiment_id = self.chaos_experiment.create(network_chaos)
        print(f"网络分区已创建，实验ID: {experiment_id}")

        # 3. 监控系统行为
        start_time = time.time()
        failures = 0
        successes = 0

        while time.time() - start_time < duration_min * 60:
            try:
                # 尝试调用服务
                response = requests.get(
                    f"http://{service_name}.ai-production.svc.cluster.local:8080/health",
                    timeout=5
                )

                if response.status_code == 200:
                    successes += 1
                    print(f"服务健康检查成功: {response.json()}")
                else:
                    failures += 1
                    print(f"服务返回异常: {response.status_code}")

            except requests.exceptions.ConnectionError:
                failures += 1
                print("连接失败 - 网络分区生效")
            except requests.exceptions.Timeout:
                failures += 1
                print("请求超时 - 符合预期")

            time.sleep(10)  # 每10秒检查一次

        # 4. 清理故障
        self.chaos_experiment.delete(experiment_id)

        # 5. 分析结果
        total_attempts = successes + failures
        success_rate = (successes / total_attempts) * 100 if total_attempts > 0 else 0

        print(f"\n网络分区测试结果:")
        print(f"总尝试次数: {total_attempts}")
        print(f"成功次数: {successes}")
        print(f"失败次数: {failures}")
        print(f"成功率: {success_rate:.2f}%")

        # 6. 验证恢复能力
        print("验证网络恢复...")
        time.sleep(30)  # 等待网络恢复

        recovery_success = False
        for i in range(10):  # 重试10次
            try:
                response = requests.get(
                    f"http://{service_name}.ai-production.svc.cluster.local:8080/health",
                    timeout=5
                )
                if response.status_code == 200:
                    recovery_success = True
                    print("✓ 服务已成功恢复")
                    break
            except Exception:
                print(f"恢复检查 {i+1}/10 失败")
                time.sleep(3)

        return {
            "experiment_id": experiment_id,
            "success_rate": success_rate,
            "recovered": recovery_success,
            "total_attempts": total_attempts
        }

    def test_network_latency(self, service_name, latency_ms=1000):
        """
        测试网络延迟下的服务行为
        """
        print(f"模拟网络延迟: {latency_ms}ms")

        # 创建延迟规则
        latency_chaos = NetworkChaos(
            name=f"network-latency-{service_name}",
            namespace="ai-production",
            action="delay",
            selector={
                "labelSelectors": {
                    "app": service_name
                }
            },
            delay={
                "latency": f"{latency_ms}ms",
                "correlation": "100",
                "jitter": "0ms"
            },
            direction="to",  # 仅对入站流量添加延迟
            duration="10m"
        )

        experiment_id = self.chaos_experiment.create(latency_chaos)

        # 测试服务超时策略
        import concurrent.futures

        def call_with_timeout(url, timeout):
            try:
                response = requests.get(url, timeout=timeout)
                return {"success": True, "status": response.status_code}
            except requests.exceptions.Timeout:
                return {"success": False, "reason": "timeout"}
            except Exception as e:
                return {"success": False, "reason": str(e)}

        # 测试不同超时设置
        test_cases = [
            {"name": "超时时间过短", "timeout": 0.5},  # 500ms < 1000ms延迟
            {"name": "超时时间适中", "timeout": 2},    # 2000ms > 1000ms延迟
            {"name": "超时时间合理", "timeout": 3},    # 3000ms，考虑抖动
        ]

        results = []
        with concurrent.futures.ThreadPoolExecutor() as executor:
            future_to_case = {
                executor.submit(
                    call_with_timeout,
                    f"http://{service_name}.ai-production.svc.cluster.local:8080/predict",
                    case["timeout"]
                ): case for case in test_cases
            }

            for future in concurrent.futures.as_completed(future_to_case):
                case = future_to_case[future]
                result = future.result()
                results.append({
                    "case": case["name"],
                    "timeout": case["timeout"],
                    **result
                })

        # 清理
        self.chaos_experiment.delete(experiment_id)

        # 输出建议
        print("\n网络延迟测试建议:")
        for result in results:
            if result["success"]:
                print(f"✓ {result['case']}: 超时{result['timeout']}s配置合理")
            else:
                print(f"✗ {result['case']}: 超时{result['timeout']}s不足，建议调整")

        return results

3. 软件故障测试：AI系统的特殊挑战

3.1 依赖服务故障模拟

AI系统通常依赖多个外部服务：特征存储、模型仓库、向量数据库等。以下Python代码展示了如何系统性地测试依赖故障：

from unittest.mock import Mock, patch, MagicMock
import pytest
import time
from typing import Dict, Any, Optional
from dataclasses import dataclass
from enum import Enum

class ServiceStatus(Enum):
    """服务状态枚举"""
    HEALTHY = "healthy"
    DEGRADED = "degraded"
    UNAVAILABLE = "unavailable"
    TIMEOUT = "timeout"

@dataclass
class DependencyConfig:
    """依赖服务配置"""
    name: str
    timeout_seconds: float
    retry_attempts: int
    retry_delay: float
    fallback_enabled: bool
    circuit_breaker_enabled: bool

class DependencyServiceMock:
    """依赖服务模拟器"""

    def __init__(self):
        self.services = {}
        self.failure_scenarios = {}

    def register_service(self, name: str, config: DependencyConfig):
        """注册依赖服务"""
        self.services[name] = {
            'config': config,
            'status': ServiceStatus.HEALTHY,
            'failure_schedule': [],
            'call_count': 0,
            'failure_count': 0
        }

    def set_failure_scenario(self, service_name: str, scenario: Dict[str, Any]):
        """
        设置故障场景
        scenario格式:
        {
            'start_time': time.time(),
            'duration': 60,
            'failure_type': 'timeout' | 'error' | 'slow',
            'failure_rate': 0.5,  # 故障概率
            'error_code': 500,
            'timeout_seconds': 10
        }
        """
        self.failure_scenarios[service_name] = scenario

    def call_service(self, service_name: str, request_data: Dict) -> Dict:
        """
        模拟调用依赖服务，根据故障场景返回相应结果
        """
        if service_name not in self.services:
            raise ValueError(f"服务未注册: {service_name}")

        service = self.services[service_name]
        service['call_count'] += 1

        # 检查是否在故障场景中
        current_time = time.time()
        scenario = self.failure_scenarios.get(service_name)

        if scenario and scenario['start_time'] <= current_time <= scenario['start_time'] + scenario['duration']:
            # 在故障时间窗口内
            import random
            if random.random() < scenario['failure_rate']:
                service['failure_count'] += 1
                service['status'] = ServiceStatus.UNAVAILABLE

                failure_type = scenario['failure_type']

                if failure_type == 'timeout':
                    time.sleep(scenario['timeout_seconds'])
                    raise TimeoutError(f"服务 {service_name} 响应超时")
                elif failure_type == 'error':
                    return {
                        'success': False,
                        'error_code': scenario['error_code'],
                        'message': f"服务 {service_name} 内部错误"
                    }
                elif failure_type == 'slow':
                    # 慢响应，但不超时
                    delay = scenario.get('slow_delay', 5)
                    time.sleep(delay)
                    service['status'] = ServiceStatus.DEGRADED

        # 正常响应
        service['status'] = ServiceStatus.HEALTHY
        return {
            'success': True,
            'data': {
                'processed': True,
                'request_id': f"req_{service['call_count']}",
                'timestamp': current_time
            }
        }

class AIServiceWithDependencies:
    """带有依赖服务的AI服务示例"""

    def __init__(self):
        self.dependencies = DependencyServiceMock()

        # 注册依赖服务
        self.dependencies.register_service(
            "feature_store",
            DependencyConfig(
                name="feature_store",
                timeout_seconds=2.0,
                retry_attempts=3,
                retry_delay=0.5,
                fallback_enabled=True,
                circuit_breaker_enabled=True
            )
        )

        self.dependencies.register_service(
            "model_registry",
            DependencyConfig(
                name="model_registry",
                timeout_seconds=5.0,
                retry_attempts=2,
                retry_delay=1.0,
                fallback_enabled=False,  # 模型服务通常无法降级
                circuit_breaker_enabled=True
            )
        )

        self.circuit_breaker_state = {}
        self.cache = {}

    def get_features_with_resilience(self, user_id: str) -> Dict:
        """
        具有容错能力的特征获取
        """
        cache_key = f"features_{user_id}"

        # 1. 检查缓存
        if cache_key in self.cache:
            cached_data = self.cache[cache_key]
            if time.time() - cached_data['timestamp'] < 300:  # 5分钟缓存
                print(f"使用缓存特征 for user {user_id}")
                return cached_data['data']

        # 2. 检查熔断器
        if self.circuit_breaker_state.get('feature_store') == 'open':
            print("特征服务熔断器开启，使用降级特征")
            return self._get_fallback_features(user_id)

        # 3. 调用服务（带重试）
        max_retries = self.dependencies.services['feature_store']['config'].retry_attempts
        retry_delay = self.dependencies.services['feature_store']['config'].retry_delay

        last_exception = None
        for attempt in range(max_retries + 1):  # +1 for initial attempt
            try:
                if attempt > 0:
                    print(f"特征服务重试 {attempt}/{max_retries}")
                    time.sleep(retry_delay * (2 ** (attempt - 1)))  # 指数退避

                features = self.dependencies.call_service(
                    "feature_store",
                    {"user_id": user_id, "action": "get_features"}
                )

                # 成功，更新缓存和熔断器状态
                self.circuit_breaker_state['feature_store'] = 'closed'

                # 缓存结果
                self.cache[cache_key] = {
                    'data': features,
                    'timestamp': time.time()
                }

                return features

            except TimeoutError as e:
                last_exception = e
                print(f"特征服务超时: {e}")

            except Exception as e:
                last_exception = e
                print(f"特征服务错误: {e}")
                break  # 非超时错误不重试

        # 所有重试失败
        print("特征服务所有重试失败")

        # 更新熔断器状态
        failure_count = self.circuit_breaker_state.get('feature_store_failures', 0) + 1
        self.circuit_breaker_state['feature_store_failures'] = failure_count

        if failure_count >= 5:  # 连续5次失败，开启熔断
            self.circuit_breaker_state['feature_store'] = 'open'
            print("特征服务熔断器开启")

        # 返回降级结果
        return self._get_fallback_features(user_id)

    def _get_fallback_features(self, user_id: str) -> Dict:
        """降级特征获取策略"""
        # 1. 返回通用特征
        # 2. 使用历史特征
        # 3. 返回空特征但标记为降级
        return {
            'success': True,
            'data': {
                'user_id': user_id,
                'features': [0.1, 0.2, 0.3],  # 通用特征
                'is_fallback': True,
                'reason': 'dependency_failure'
            },
            'metadata': {
                'source': 'fallback',
                'timestamp': time.time()
            }
        }

# 测试用例
def test_dependency_resilience():
    """依赖服务容错测试"""

    print("=== 依赖服务容错测试开始 ===")

    # 创建AI服务
    ai_service = AIServiceWithDependencies()

    # 测试场景1: 正常情况
    print("\n场景1: 正常请求")
    result = ai_service.get_features_with_resilience("user_123")
    print(f"结果: {result['success']}")

    # 测试场景2: 设置特征服务超时故障
    print("\n场景2: 特征服务超时故障")
    ai_service.dependencies.set_failure_scenario("feature_store", {
        'start_time': time.time(),
        'duration': 30,
        'failure_type': 'timeout',
        'failure_rate': 1.0,  # 100%故障率
        'timeout_seconds': 3  # 3秒超时
    })

    start_time = time.time()
    result = ai_service.get_features_with_resilience("user_456")
    elapsed = time.time() - start_time

    print(f"结果: {result['success']}, 耗时: {elapsed:.2f}s")
    print(f"是否降级: {result['data'].get('is_fallback', False)}")

    # 测试场景3: 验证熔断器
    print("\n场景3: 验证熔断器生效")
    # 连续多次失败应该触发熔断
    for i in range(6):
        result = ai_service.get_features_with_resilience(f"user_{i}")
        print(f"请求 {i+1}: 熔断状态={ai_service.circuit_breaker_state.get('feature_store')}")

    # 测试场景4: 恢复测试
    print("\n场景4: 服务恢复测试")
    # 清除故障场景
    ai_service.dependencies.failure_scenarios.clear()

    # 熔断器应在一段时间后尝试恢复（半开状态）
    time.sleep(30)  # 模拟恢复等待时间

    result = ai_service.get_features_with_resilience("user_recovery")
    print(f"恢复后结果: {result['success']}")
    print(f"熔断器状态: {ai_service.circuit_breaker_state.get('feature_store')}")

if __name__ == "__main__":
    test_dependency_resilience()

3.2 模型服务故障测试

模型服务是AI系统的核心，其故障测试需要特殊关注：

import java.util.concurrent.*;
import java.util.function.Supplier;

public class ModelServiceResilienceTest {

    /**
     * 模型加载失败测试
     */
    public static class ModelLoader {
        private volatile boolean modelLoaded = false;
        private volatile String currentModelVersion = null;
        private final ScheduledExecutorService healthCheckScheduler;
        private final Object loadLock = new Object();

        public ModelLoader() {
            this.healthCheckScheduler = Executors.newScheduledThreadPool(1);
            startHealthChecks();
        }

        /**
         * 模拟模型加载（可能失败）
         */
        public boolean loadModel(String modelPath, String version) {
            synchronized (loadLock) {
                System.out.printf("开始加载模型: %s, 版本: %s%n", modelPath, version);

                // 模拟随机失败（生产环境可能是文件损坏、格式错误等）
                double failureRate = 0.1; // 10%失败率
                if (Math.random() < failureRate) {
                    System.out.println("模型加载失败: 文件损坏");
                    modelLoaded = false;
                    return false;
                }

                // 模拟加载时间
                try {
                    Thread.sleep(2000 + (long)(Math.random() * 1000));
                } catch (InterruptedException e) {
                    Thread.currentThread().interrupt();
                }

                currentModelVersion = version;
                modelLoaded = true;
                System.out.println("模型加载成功");
                return true;
            }
        }

        /**
         * 带重试的模型加载
         */
        public boolean loadModelWithRetry(String modelPath, String version,
                                         int maxAttempts, long retryDelayMs) {
            for (int attempt = 1; attempt <= maxAttempts; attempt++) {
                System.out.printf("模型加载尝试 %d/%d%n", attempt, maxAttempts);

                boolean success = loadModel(modelPath, version);
                if (success) {
                    return true;
                }

                if (attempt < maxAttempts) {
                    System.out.printf("加载失败，%dms后重试...%n", retryDelayMs);
                    try {
                        Thread.sleep(retryDelayMs);
                        // 指数退避
                        retryDelayMs = Math.min(retryDelayMs * 2, 30000); // 最大30秒
                    } catch (InterruptedException e) {
                        Thread.currentThread().interrupt();
                        break;
                    }
                }
            }

            System.out.println("所有重试尝试均失败");
            return false;
        }

        /**
         * 模型推理（模拟可能失败）
         */
        public CompletableFuture<PredictionResult> predictAsync(double[] input) {
            CompletableFuture<PredictionResult> future = new CompletableFuture<>();

            // 检查模型是否加载
            if (!modelLoaded) {
                future.completeExceptionally(
                    new IllegalStateException("模型未加载")
                );
                return future;
            }

            // 模拟推理执行（可能超时或异常）
            Executors.newSingleThreadExecutor().submit(() -> {
                try {
                    // 模拟推理时间（随机可能超长）
                    long inferenceTime = 100 + (long)(Math.random() * 5000);

                    // 5%概率模拟超长推理
                    if (Math.random() < 0.05) {
                        inferenceTime = 10000; // 10秒超长
                    }

                    Thread.sleep(inferenceTime);

                    // 2%概率模拟推理异常
                    if (Math.random() < 0.02) {
                        throw new RuntimeException("模型推理异常: 数值溢出");
                    }

                    // 模拟推理结果
                    PredictionResult result = new PredictionResult();
                    result.setSuccess(true);
                    result.setPrediction(new double[]{Math.random()});
                    result.setModelVersion(currentModelVersion);
                    result.setInferenceTimeMs(inferenceTime);

                    future.complete(result);

                } catch (InterruptedException e) {
                    future.completeExceptionally(e);
                    Thread.currentThread().interrupt();
                } catch (Exception e) {
                    future.completeExceptionally(e);
                }
            });

            return future;
        }

        /**
         * 带超时和降级的预测
         */
        public PredictionResult predictWithFallback(double[] input,
                                                   long timeoutMs,
                                                   Supplier<PredictionResult> fallback) {
            CompletableFuture<PredictionResult> future = predictAsync(input);

            try {
                // 等待结果，超时则使用降级策略
                return future.get(timeoutMs, TimeUnit.MILLISECONDS);
            } catch (TimeoutException e) {
                System.out.printf("预测超时 (%dms)，使用降级策略%n", timeoutMs);
                return fallback.get();
            } catch (Exception e) {
                System.out.println("预测异常: " + e.getMessage());
                return fallback.get();
            }
        }

        /**
         * 健康检查定时任务
         */
        private void startHealthChecks() {
            healthCheckScheduler.scheduleAtFixedRate(() -> {
                if (modelLoaded) {
                    // 执行快速健康检查
                    try {
                        double[] testInput = new double[10];
                        CompletableFuture<PredictionResult> testFuture = predictAsync(testInput);

                        testFuture.get(2000, TimeUnit.MILLISECONDS);
                        System.out.println("模型健康检查: ✓");
                    } catch (TimeoutException e) {
                        System.out.println("模型健康检查: ✗ (超时)");
                        modelLoaded = false; // 标记为不健康
                    } catch (Exception e) {
                        System.out.println("模型健康检查: ✗ (" + e.getMessage() + ")");
                        modelLoaded = false;
                    }
                }
            }, 30, 30, TimeUnit.SECONDS); // 每30秒检查一次
        }

        public void shutdown() {
            healthCheckScheduler.shutdown();
        }
    }

    /**
     * 预测结果类
     */
    public static class PredictionResult {
        private boolean success;
        private double[] prediction;
        private String modelVersion;
        private long inferenceTimeMs;
        private boolean isFallback;
        private String fallbackReason;

        // getters and setters
        public boolean isSuccess() { return success; }
        public void setSuccess(boolean success) { this.success = success; }

        public double[] getPrediction() { return prediction; }
        public void setPrediction(double[] prediction) { this.prediction = prediction; }

        public String getModelVersion() { return modelVersion; }
        public void setModelVersion(String modelVersion) { this.modelVersion = modelVersion; }

        public long getInferenceTimeMs() { return inferenceTimeMs; }
        public void setInferenceTimeMs(long inferenceTimeMs) { this.inferenceTimeMs = inferenceTimeMs; }

        public boolean isFallback() { return isFallback; }
        public void setFallback(boolean fallback) { isFallback = fallback; }

        public String getFallbackReason() { return fallbackReason; }
        public void setFallbackReason(String fallbackReason) { this.fallbackReason = fallbackReason; }
    }

    /**
     * 降级策略提供者
     */
    public static class FallbackStrategies {
        public static PredictionResult defaultPrediction() {
            PredictionResult result = new PredictionResult();
            result.setSuccess(true);
            result.setPrediction(new double[]{0.5}); // 默认预测值
            result.setFallback(true);
            result.setFallbackReason("model_service_failure");
            return result;
        }

        public static PredictionResult cachedPrediction(double[] cachedResult) {
            PredictionResult result = new PredictionResult();
            result.setSuccess(true);
            result.setPrediction(cachedResult);
            result.setFallback(true);
            result.setFallbackReason("using_cached_result");
            return result;
        }

        public static PredictionResult simplifiedModelPrediction(double[] input) {
            // 使用简化模型计算
            double sum = 0;
            for (double v : input) {
                sum += v;
            }
            double avg = sum / input.length;

            PredictionResult result = new PredictionResult();
            result.setSuccess(true);
            result.setPrediction(new double[]{avg});
            result.setFallback(true);
            result.setFallbackReason("simplified_model");
            return result;
        }
    }

    /**
     * 运行模型服务容错测试
     */
    public static void runModelServiceTests() throws Exception {
        System.out.println("=== 模型服务容错测试 ===");

        ModelLoader modelLoader = new ModelLoader();

        try {
            // 测试1: 模型加载重试
            System.out.println("\n测试1: 模型加载重试机制");
            boolean loaded = modelLoader.loadModelWithRetry(
                "/models/recommendation/v1",
                "v1.2.3",
                3,
                1000
            );
            System.out.println("模型加载结果: " + (loaded ? "成功" : "失败"));

            if (loaded) {
                // 测试2: 推理超时处理
                System.out.println("\n测试2: 推理超时与降级");
                double[] testInput = new double[100];
                for (int i = 0; i < testInput.length; i++) {
                    testInput[i] = Math.random();
                }

                // 设置较短的超时时间，测试降级策略
                PredictionResult result = modelLoader.predictWithFallback(
                    testInput,
                    1000, // 1秒超时
                    FallbackStrategies::defaultPrediction
                );

                System.out.println("预测结果:");
                System.out.println("  成功: " + result.isSuccess());
                System.out.println("  降级: " + result.isFallback());
                System.out.println("  原因: " + result.getFallbackReason());
                if (result.getPrediction() != null) {
                    System.out.println("  预测值: " + result.getPrediction()[0]);
                }

                // 测试3: 批量请求下的故障处理
                System.out.println("\n测试3: 并发请求压力测试");
                int concurrentRequests = 10;
                CountDownLatch latch = new CountDownLatch(concurrentRequests);
                List<Future<PredictionResult>> futures = new ArrayList<>();
                ExecutorService executor = Executors.newFixedThreadPool(concurrentRequests);

                for (int i = 0; i < concurrentRequests; i++) {
                    final int requestId = i;
                    futures.add(executor.submit(() -> {
                        try {
                            double[] input = new double[50];
                            Arrays.fill(input, requestId * 0.1);

                            return modelLoader.predictWithFallback(
                                input,
                                3000,
                                () -> FallbackStrategies.cachedPrediction(new double[]{0.5})
                            );
                        } finally {
                            latch.countDown();
                        }
                    }));
                }

                latch.await();

                int successCount = 0;
                int fallbackCount = 0;
                for (Future<PredictionResult> future : futures) {
                    try {
                        PredictionResult pr = future.get(100, TimeUnit.MILLISECONDS);
                        if (pr.isSuccess()) successCount++;
                        if (pr.isFallback()) fallbackCount++;
                    } catch (Exception e) {
                        System.out.println("请求异常: " + e.getMessage());
                    }
                }

                System.out.println("并发测试结果:");
                System.out.println("  总请求数: " + concurrentRequests);
                System.out.println("  成功数: " + successCount);
                System.out.println("  降级数: " + fallbackCount);

                executor.shutdown();
            }

        } finally {
            modelLoader.shutdown();
        }
    }

    public static void main(String[] args) throws Exception {
        runModelServiceTests();
    }
}

（由于篇幅限制，本文只展示了部分内容。完整文章包含故障注入工具实战、容错机制验证、Vue前端容错测试、实时推荐系统实战案例、以及详细的踩坑指南等内容，总字数约12000字。）

结论

AI系统的容错测试不是一次性的任务，而是一个持续的过程。通过系统的故障注入测试，我们不仅能够发现系统的薄弱点，更能主动设计出更健壮的架构。关键收获包括：

1. 分层容错策略：从硬件到应用层，每一层都需要有针对性的容错机制
2. 智能降级：AI系统尤其需要精细化的降级策略，避免"全有或全无"的问题
3. 主动故障注入：在生产环境安全地进行故障演练，才能真正验证系统的韧性
4. 全链路监控：没有可观测性的容错是盲目的，需要完善的监控告警体系

记住：容错能力不是靠运气实现的，而是通过刻意设计和系统测试构建的。开始你的故障注入测试之旅，构建真正可靠的AI系统吧！

---

扩展阅读建议：

• Netflix Chaos Engineering实践
• Google SRE（站点可靠性工程）原则
• AWS Well-Architected Framework中的可靠性支柱
• 微服务模式：重试、熔断、限流、降级
