架构图prompt

Task: Extract Architecture Diagram to JSON
把架构图里的分层、组件、嵌套关系和组件间调用依赖，按固定JSON格式结构化提取出来，最多嵌套4层，不做深层展开

# Task: Extract Architecture Diagram to JSON

Please carefully analyze the current project. Based on your deep research, generate a detailed architecture diagram.

## Expected JSON Structure
```json
{
  "diagram": {
    "title": "string",
    "layers": [
      {
        "id": "string",
        "name": "string",
        "level": number,
        "components": [
          {
            "id": "string",
            "name": "string",
            "type": "string",
            "module": "string (optional)",
            "provider": "string (optional)",
            "dependencies": ["string array (optional)"],
            "contains": [/* nested components - MAX 3-4 LEVELS */]
          }
        ]
      }
    ],
    "relationships": [
      {
        "from": "component-id",
        "to": "component-id",
        "type": "calls | uses | depends-on | integrates-with | supports"
      }
    ]
  }
}
```

## Extraction Rules

1. **Identify Layers (Horizontal Sections)**
   - Look for dashed boxes that group components horizontally
   - Each layer has a name (usually on the left with an icon)
   - Assign level: 1 (top) → 2 (middle) → 3 (bottom)

2. **Extract Components**
   - Component name: Bold text inside boxes
   - Component type: Text in parentheses below name (e.g., "ui-module", "framework")
   - For nested components (like Tools containing multiple tools), use the `contains` array
   - **IMPORTANT: Maximum nesting depth is 3-4 levels**
   - Generate kebab-case IDs from component names

3. **Nesting Structure Guidelines**
   - Level 1: Layer (e.g., "Console UI", "Agentic System")
   - Level 2: Major component (e.g., "Components", "Tools")
   - Level 3: Sub-component (e.g., "File System Toolset", "Text Editor Tool")
   - Level 4 (if needed): Detailed sub-item (e.g., specific tool functions)
   - **Stop at level 4 - do not nest deeper**

4. **Identify Relationships**
   - Arrows between components indicate relationships
   - Bidirectional arrows (↔) = "integrates-with"
   - Downward arrows (↓) = "depends-on"
   - Arrows pointing to specific components = "calls" or "uses"

5. **Special Cases**
   - If a component contains a list of items (like "Tools" containing "File System Toolset", "Text Editor Tool", etc.), put them in the `contains` array
   - Keep the exact naming from the diagram
   - For module names in parentheses, add them as a `module` field
   - If you encounter deeper nesting in the diagram, flatten it to maximum 4 levels

## Example Nesting
```json
{
  "layers": [                           // Level 1
    {
      "components": [                   // Level 2
        {
          "id": "tools",
          "name": "Tools",
          "contains": [                 // Level 3
            {
              "id": "filesystem-tool",
              "name": "File System Toolset",
              "contains": [             // Level 4 (MAX)
                {
                  "id": "read-file",
                  "name": "Read File"
                }
              ]
            }
          ]
        }
      ]
    }
  ]
}
```

## Output

Please provide:
1. The complete JSON structure (respecting max 3-4 level nesting)
2. Reference documents are under `doc` folder and README.md if exists
3. A brief summary of:
   - Layer count
   - Component count
   - Maximum nesting depth used
   - Relationship count
4. If you had to flatten any structure, mention what was simplified
