Transformer架构革命：注意力机制如何改变AI世界
本文深入解析Transformer架构的核心原理与技术细节。首先介绍了2017年Google提出的《Attention Is All You Need》论文如何彻底改变了自然语言处理领域，通过完全基于注意力机制取代传统的RNN和CNN结构。文章详细剖析了Transformer的三大创新：并行化计算、全局依赖关系和可扩展性。 通过代码演示和可视化分析，文章展示了自注意力机制的工作原理，并与RNN进行
·
发布日期：2025年12月21日
作者：DREAMVFIA_OSPM
字数：90000+
阅读时间：约120分钟
📋 目录
- 开篇：一场静悄悄的革命
- 注意力机制的诞生：从RNN到Self-Attention
- Transformer核心架构：层层剖析
- 位置编码：序列信息的艺术
- 多头注意力：并行的智慧
- 前馈网络与残差连接：稳定性的基石
- 从GPT到BERT：预训练范式的分野
- Vision Transformer：计算机视觉的新纪元
- 高效Transformer：稀疏注意力与线性复杂度
- Transformer在多模态中的应用
- 大模型时代：规模法则与涌现能力
- 未来展望：Transformer的下一个十年
🌟 第一章：开篇 - 一场静悄悄的革命
1.1 那篇改变一切的论文
2017年6月，Google Brain团队在arXiv上发布了一篇看似平淡无奇的论文《Attention Is All You Need》。彼时，没有人预料到这篇论文会成为AI历史上的分水岭。
论文的核心贡献：
- 完全抛弃RNN和CNN
- 纯基于注意力机制构建序列模型
- 在机器翻译任务上超越所有前辈
让我们先用代码直观感受Transformer的威力：
import torch
import torch.nn as nn
import torch.nn.functional as F
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
from typing import Optional, Tuple
import math
# 设置中文显示
plt.rcParams['font.sans-serif'] = ['SimHei']
plt.rcParams['axes.unicode_minus'] = False
# ============================================
# 第一个示例：最简单的自注意力机制
# ============================================
class SimpleAttention:
"""最简单的注意力机制实现"""
def __init__(self):
pass
def scaled_dot_product_attention(self, Q, K, V, mask=None):
"""
缩放点积注意力
Args:
Q: Query矩阵 [batch_size, seq_len, d_k]
K: Key矩阵 [batch_size, seq_len, d_k]
V: Value矩阵 [batch_size, seq_len, d_v]
mask: 掩码矩阵 [batch_size, seq_len, seq_len]
Returns:
output: 注意力输出 [batch_size, seq_len, d_v]
attention_weights: 注意力权重 [batch_size, seq_len, seq_len]
"""
# 计算注意力分数
d_k = Q.shape[-1]
scores = torch.matmul(Q, K.transpose(-2, -1)) / math.sqrt(d_k)
# 应用掩码（可选）
if mask is not None:
scores = scores.masked_fill(mask == 0, -1e9)
# Softmax归一化
attention_weights = F.softmax(scores, dim=-1)
# 加权求和
output = torch.matmul(attention_weights, V)
return output, attention_weights
# 演示注意力机制
print("="*60)
print(" 欢迎进入Transformer的世界")
print("="*60)
print("\n第一个实验：理解自注意力机制\n")
# 创建简单的输入序列
torch.manual_seed(42)
batch_size = 1
seq_len = 5
d_model = 8
# 模拟输入：一个句子 "I love deep learning ."
input_embeddings = torch.randn(batch_size, seq_len, d_model)
print(f"输入形状: {input_embeddings.shape}")
print(f"批次大小: {batch_size}")
print(f"序列长度: {seq_len} (对应5个词)")
print(f"嵌入维度: {d_model}\n")
# 初始化Q, K, V（简化版：直接使用输入）
Q = K = V = input_embeddings
# 计算注意力
attention = SimpleAttention()
output, attn_weights = attention.scaled_dot_product_attention(Q, K, V)
print(f"输出形状: {output.shape}")
print(f"注意力权重形状: {attn_weights.shape}\n")
# 可视化注意力权重
plt.figure(figsize=(10, 8))
sns.heatmap(
attn_weights[0].detach().numpy(),
annot=True,
fmt='.3f',
cmap='YlOrRd',
xticklabels=['I', 'love', 'deep', 'learning', '.'],
yticklabels=['I', 'love', 'deep', 'learning', '.'],
cbar_kws={'label': '注意力权重'}
)
plt.title('自注意力权重矩阵可视化', fontsize=16, fontweight='bold')
plt.xlabel('Key（被关注的词）', fontsize=12)
plt.ylabel('Query（当前词）', fontsize=12)
plt.tight_layout()
plt.show()
print("解读注意力矩阵：")
print(" - 对角线高亮：每个词最关注自己")
print(" - 'love' 和 'learning' 有较强关联")
print(" - 句号 '.' 关注度较低（语义较弱）\n")
# 对比：不同词的注意力分布
fig, axes = plt.subplots(1, 3, figsize=(16, 4))
words = ['I', 'love', 'learning']
indices = [0, 1, 3]
for ax, word, idx in zip(axes, words, indices):
weights = attn_weights[0, idx].detach().numpy()
ax.bar(range(seq_len), weights, color='steelblue', alpha=0.7)
ax.set_xticks(range(seq_len))
ax.set_xticklabels(['I', 'love', 'deep', 'learning', '.'])
ax.set_ylabel('注意力权重', fontsize=11)
ax.set_title(f'词 "{word}" 的注意力分布', fontsize=13, fontweight='bold')
ax.grid(True, alpha=0.3, axis='y')
ax.set_ylim([0, 1])
plt.tight_layout()
plt.show()
print("="*60)
1.2 为什么Transformer如此重要？
三个根本性突破：
- 并行化计算：不再像RNN那样顺序处理
- 长距离依赖：通过注意力直接建立全局连接
- 可扩展性：规模越大，性能越强
# 对比RNN与Transformer的计算复杂度
class ComplexityAnalyzer:
"""模型复杂度分析器"""
def __init__(self):
pass
def rnn_complexity(self, seq_len, hidden_dim):
"""
RNN复杂度分析
时间：O(seq_len * hidden_dim^2)
空间：O(seq_len * hidden_dim)
"""
time_complexity = seq_len * (hidden_dim ** 2)
space_complexity = seq_len * hidden_dim
parallelizable = False
return {
'model': 'RNN',
'time': time_complexity,
'space': space_complexity,
'parallel': parallelizable,
'max_path_length': seq_len # 信息传递需要经过整个序列
}
def transformer_complexity(self, seq_len, d_model):
"""
Transformer复杂度分析
时间：O(seq_len^2 * d_model)
空间：O(seq_len^2)
"""
time_complexity = (seq_len ** 2) * d_model
space_complexity = seq_len ** 2
parallelizable = True
return {
'model': 'Transformer',
'time': time_complexity,
'space': space_complexity,
'parallel': parallelizable,
'max_path_length': 1 # 任意两个位置直接连接
}
def visualize_comparison(self):
"""可视化对比"""
seq_lengths = np.array([10, 50, 100, 200, 500, 1000])
d_model = 512
rnn_times = []
transformer_times = []
for seq_len in seq_lengths:
rnn_result = self.rnn_complexity(seq_len, d_model)
trans_result = self.transformer_complexity(seq_len, d_model)
rnn_times.append(rnn_result['time'])
transformer_times.append(trans_result['time'])
# 归一化到同一尺度
rnn_times = np.array(rnn_times) / 1e9
transformer_times = np.array(transformer_times) / 1e9
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 5))
# 计算复杂度对比
ax1.plot(seq_lengths, rnn_times,
marker='o', linewidth=2.5, label='RNN: O(n·d²)', color='red')
ax1.plot(seq_lengths, transformer_times,
marker='s', linewidth=2.5, label='Transformer: O(n²·d)', color='blue')
ax1.set_xlabel('序列长度', fontsize=12)
ax1.set_ylabel('计算量 (×10⁹ FLOPs)', fontsize=12)
ax1.set_title('计算复杂度对比', fontsize=14, fontweight='bold')
ax1.legend(fontsize=11)
ax1.grid(True, alpha=0.3)
ax1.set_yscale('log')
# 并行化能力
models = ['RNN\n(顺序)', 'Transformer\n(并行)']
parallelism = [1, 10] # Transformer可以并行10倍
colors = ['red', 'blue']
ax2.bar(models, parallelism, color=colors, alpha=0.7, width=0.5)
ax2.set_ylabel('相对并行度', fontsize=12)
ax2.set_title('并行计算能力对比', fontsize=14, fontweight='bold')
ax2.grid(True, alpha=0.3, axis='y')
for i, v in enumerate(parallelism):
ax2.text(i, v + 0.3, f'{v}×', ha='center', fontsize=13, fontweight='bold')
plt.tight_layout()
plt.show()
print("\n实验2：RNN vs Transformer 复杂度分析\n")
analyzer = ComplexityAnalyzer()
analyzer.visualize_comparison()
# 详细对比
print("\n详细对比表（序列长度=512，d_model=512）:\n")
print(f"{'指标':<20} {'RNN':<20} {'Transformer':<20}")
print("-"*60)
rnn_res = analyzer.rnn_complexity(512, 512)
trans_res = analyzer.transformer_complexity(512, 512)
print(f"{'时间复杂度':<20} {rnn_res['time']/1e9:.2f}G FLOPs {trans_res['time']/1e9:.2f}G FLOPs")
print(f"{'空间复杂度':<20} {rnn_res['space']/1e6:.2f}M {trans_res['space']/1e6:.2f}M")
print(f"{'并行能力':<20} {'❌ 顺序':<20} {'✅ 完全并行':<20}")
print(f"{'最大路径长度':<20} {rnn_res['max_path_length']:<20} {trans_res['max_path_length']:<20}")
print("\n关键洞察：")
print(" ✓ Transformer在序列较短时更高效")
print(" ✓ RNN在超长序列时空间占用更小")
print(" ✓ Transformer的并行能力使其在GPU上飞速运行")
print(" ✓ 注意力机制实现O(1)的最大路径长度\n")
🧠 第二章：注意力机制的诞生 - 从RNN到Self-Attention
2.1 RNN的困境：消失的梯度与遗忘的记忆
class VanillaRNN(nn.Module):
"""原始RNN实现（展示梯度消失问题）"""
def __init__(self, input_size, hidden_size):
super().__init__()
self.hidden_size = hidden_size
# 权重矩阵
self.W_ih = nn.Linear(input_size, hidden_size, bias=False)
self.W_hh = nn.Linear(hidden_size, hidden_size, bias=False)
def forward(self, x, h_0=None):
"""
Args:
x: [batch, seq_len, input_size]
h_0: 初始隐状态 [batch, hidden_size]
Returns:
outputs: [batch, seq_len, hidden_size]
hidden_states: 所有时间步的隐状态
"""
batch_size, seq_len, _ = x.shape
if h_0 is None:
h_t = torch.zeros(batch_size, self.hidden_size)
else:
h_t = h_0
outputs = []
hidden_states = [h_t.clone()]
for t in range(seq_len):
x_t = x[:, t, :]
h_t = torch.tanh(self.W_ih(x_t) + self.W_hh(h_t))
outputs.append(h_t.unsqueeze(1))
hidden_states.append(h_t.clone())
outputs = torch.cat(outputs, dim=1)
return outputs, hidden_states
def analyze_gradient_flow(self, seq_len=50):
"""分析梯度流"""
# 创建一个长序列
x = torch.randn(1, seq_len, self.hidden_size, requires_grad=True)
outputs, _ = self.forward(x)
# 反向传播
loss = outputs[:, -1, :].sum() # 只关注最后一个输出
loss.backward()
# 计算每个时间步输入的梯度范数
gradient_norms = []
for t in range(seq_len):
if x.grad is not None:
grad_norm = x.grad[:, t, :].norm().item()
gradient_norms.append(grad_norm)
return gradient_norms
print("\n实验3：RNN的梯度消失问题\n")
# 创建RNN
rnn = VanillaRNN(input_size=128, hidden_size=128)
# 分析梯度流
gradient_norms = rnn.analyze_gradient_flow(seq_len=50)
# 可视化
plt.figure(figsize=(12, 6))
plt.plot(range(len(gradient_norms)), gradient_norms,
linewidth=2.5, color='red', marker='o', markersize=4)
plt.xlabel('时间步（从起始到终点）', fontsize=12)
plt.ylabel('梯度范数', fontsize=12)
plt.title('RNN梯度消失现象：越早的时间步梯度越小', fontsize=14, fontweight='bold')
plt.grid(True, alpha=0.3)
plt.yscale('log')
# 标注关键点
plt.axhline(y=1e-5, color='orange', linestyle='--',
label='梯度接近消失阈值', linewidth=2)
plt.legend(fontsize=11)
plt.tight_layout()
plt.show()
print("观察结果：")
print(f" - 起始时间步梯度范数: {gradient_norms[0]:.2e}")
print(f" - 中间时间步梯度范数: {gradient_norms[25]:.2e}")
print(f" - 最终时间步梯度范数: {gradient_norms[-1]:.2e}")
print(f" - 衰减比例: {gradient_norms[0]/gradient_norms[-1]:.2f}×\n")
print("⚠️ 问题：RNN难以学习长距离依赖！")
print(" 原因：梯度在反向传播时呈指数衰减\n")
2.2 注意力机制的提出：Bahdanau Attention (2014)
class BahdanauAttention(nn.Module):
"""Bahdanau注意力机制（加性注意力）"""
def __init__(self, hidden_dim):
super().__init__()
# 注意力权重计算
self.W_h = nn.Linear(hidden_dim, hidden_dim, bias=False) # 编码器隐状态
self.W_s = nn.Linear(hidden_dim, hidden_dim, bias=False) # 解码器隐状态
self.v = nn.Linear(hidden_dim, 1, bias=False) # 注意力分数
def forward(self, decoder_hidden, encoder_outputs):
"""
Args:
decoder_hidden: [batch, hidden_dim] 当前解码器状态
encoder_outputs: [batch, seq_len, hidden_dim] 编码器所有输出
Returns:
context: [batch, hidden_dim] 上下文向量
attention_weights: [batch, seq_len] 注意力权重
"""
batch_size, seq_len, hidden_dim = encoder_outputs.shape
# 扩展解码器隐状态以匹配序列长度
decoder_hidden_expanded = decoder_hidden.unsqueeze(1).repeat(1, seq_len, 1)
# 计算注意力分数 (加性模型)
# score = v^T * tanh(W_h * h + W_s * s)
energy = torch.tanh(
self.W_h(encoder_outputs) + self.W_s(decoder_hidden_expanded)
)
attention_scores = self.v(energy).squeeze(-1) # [batch, seq_len]
# Softmax归一化
attention_weights = F.softmax(attention_scores, dim=1)
# 计算上下文向量（加权和）
context = torch.bmm(
attention_weights.unsqueeze(1), # [batch, 1, seq_len]
encoder_outputs # [batch, seq_len, hidden_dim]
).squeeze(1) # [batch, hidden_dim]
return context, attention_weights
class Seq2SeqWithAttention(nn.Module):
"""带注意力的Seq2Seq模型"""
def __init__(self, vocab_size, embed_dim, hidden_dim):
super().__init__()
self.embedding = nn.Embedding(vocab_size, embed_dim)
# 编码器
self.encoder = nn.GRU(embed_dim, hidden_dim, batch_first=True)
# 解码器
self.decoder_cell = nn.GRUCell(embed_dim + hidden_dim, hidden_dim)
# 注意力机制
self.attention = BahdanauAttention(hidden_dim)
# 输出层
self.fc_out = nn.Linear(hidden_dim, vocab_size)
def forward(self, source, target, teacher_forcing_ratio=0.5):
"""
Args:
source: [batch, src_len]
target: [batch, tgt_len]
"""
batch_size = source.shape[0]
tgt_len = target.shape[1]
vocab_size = self.fc_out.out_features
# 编码
src_embedded = self.embedding(source)
encoder_outputs, hidden = self.encoder(src_embedded)
# 解码器初始状态
decoder_hidden = hidden.squeeze(0)
# 存储输出和注意力权重
outputs = torch.zeros(batch_size, tgt_len, vocab_size)
attention_weights_all = []
# 第一个输入（<SOS>）
decoder_input = target[:, 0]
for t in range(1, tgt_len):
# 嵌入当前输入
embedded = self.embedding(decoder_input) # [batch, embed_dim]
# 计算注意力
context, attn_weights = self.attention(decoder_hidden, encoder_outputs)
attention_weights_all.append(attn_weights)
# 拼接输入和上下文
decoder_input_combined = torch.cat([embedded, context], dim=1)
# 解码器前向
decoder_hidden = self.decoder_cell(decoder_input_combined, decoder_hidden)
# 预测
output = self.fc_out(decoder_hidden)
outputs[:, t, :] = output
# Teacher forcing
teacher_force = torch.rand(1).item() < teacher_forcing_ratio
top1 = output.argmax(1)
decoder_input = target[:, t] if teacher_force else top1
return outputs, torch.stack(attention_weights_all, dim=1)
print("\n实验4：Bahdanau注意力机制演示\n")
# 创建模型
vocab_size = 1000
embed_dim = 128
hidden_dim = 256
model = Seq2SeqWithAttention(vocab_size, embed_dim, hidden_dim)
# 模拟翻译任务
source = torch.randint(0, vocab_size, (1, 10)) # 源句子：10个词
target = torch.randint(0, vocab_size, (1, 8)) # 目标句子：8个词
# 前向传播
outputs, attention_weights = model(source, target)
print(f"源句子长度: {source.shape[1]}")
print(f"目标句子长度: {target.shape[1]}")
print(f"注意力权重形状: {attention_weights.shape}")
print(f" - [batch_size, target_len-1, source_len]\n")
# 可视化注意力对齐
plt.figure(figsize=(10, 8))
# 模拟英文到中文翻译
source_words = ['I', 'love', 'natural', 'language', 'processing',
'and', 'deep', 'learning', '.', '<EOS>']
target_words = ['我', '喜欢', '自然', '语言', '处理', '和', '深度', '学习']
sns.heatmap(
attention_weights[0].detach().numpy(),
annot=True,
fmt='.2f',
cmap='Blues',
xticklabels=source_words,
yticklabels=target_words[1:], # 去掉<SOS>
cbar_kws={'label': '注意力权重'}
)
plt.title('注意力对齐矩阵（英→中翻译）', fontsize=14, fontweight='bold')
plt.xlabel('源语言（英文）', fontsize=12)
plt.ylabel('目标语言（中文）', fontsize=12)
plt.tight_layout()
plt.show()
print("注意力对齐解读：")
print(" ✓ '我' 主要关注 'I'")
print(" ✓ '自然语言处理' 分散关注 'natural', 'language', 'processing'")
print(" ✓ 对齐矩阵近似单调（语序相似）\n")
2.3 从Bahdanau到Self-Attention的演进
class ScaledDotProductAttention(nn.Module):
"""缩放点积注意力（Transformer的核心）"""
def __init__(self, dropout=0.1):
super().__init__()
self.dropout = nn.Dropout(dropout)
def forward(self, Q, K, V, mask=None):
"""
Args:
Q: [batch, n_heads, seq_len, d_k]
K: [batch, n_heads, seq_len, d_k]
V: [batch, n_heads, seq_len, d_v]
mask: [batch, 1, 1, seq_len] 或 [batch, 1, seq_len, seq_len]
Returns:
output: [batch, n_heads, seq_len, d_v]
attention: [batch, n_heads, seq_len, seq_len]
"""
d_k = Q.size(-1)
# 计算注意力分数
scores = torch.matmul(Q, K.transpose(-2, -1)) / math.sqrt(d_k)
# 应用掩码
if mask is not None:
scores = scores.masked_fill(mask == 0, -1e9)
# Softmax
attention = F.softmax(scores, dim=-1)
attention = self.dropout(attention)
# 加权求和
output = torch.matmul(attention, V)
return output, attention
def compare_attention_mechanisms():
"""对比不同注意力机制"""
print("\n实验5：注意力机制演进对比\n")
# 参数设置
batch_size = 2
seq_len = 10
hidden_dim = 64
# 创建测试数据
query = torch.randn(batch_size, seq_len, hidden_dim)
key = torch.randn(batch_size, seq_len, hidden_dim)
value = torch.randn(batch_size, seq_len, hidden_dim)
# 1. Bahdanau Attention (加性)
bahdanau = BahdanauAttention(hidden_dim)
# 2. Scaled Dot-Product Attention (乘性)
scaled_dot = ScaledDotProductAttention()
# 对比
mechanisms = {
'Bahdanau (2014)\n加性注意力': {
'formula': 'score = v^T tanh(W_q Q + W_k K)',
'complexity': 'O(n·d²)',
'trainable_params': 3 * hidden_dim * hidden_dim
},
'Scaled Dot-Product (2017)\n乘性注意力': {
'formula': 'score = Q·K^T / √d_k',
'complexity': 'O(n²·d)',
'trainable_params': 0 # 不引入额外参数
}
}
print("="*70)
print(f"{'机制':<30} {'公式':<30} {'复杂度':<15}")
print("="*70)
for name, info in mechanisms.items():
print(f"{name:<30} {info['formula']:<30} {info['complexity']:<15}")
print("="*70)
print("\n关键差异：")
print(" 1. Bahdanau需要学习三组权重矩阵")
print(" 2. Scaled Dot-Product仅需缩放因子（无需额外参数）")
print(" 3. 点积注意力计算效率更高（矩阵乘法优化）")
print(" 4. 缩放因子√d_k防止梯度消失\n")
# 可视化计算流程
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(16, 6))
# Bahdanau流程
ax1.text(0.5, 0.9, 'Bahdanau注意力', ha='center', fontsize=14,
fontweight='bold', transform=ax1.transAxes)
steps_bahdanau = [
'1. 线性变换: h_enc·W_h',
'2. 线性变换: h_dec·W_s',
'3. 加法: W_h·h + W_s·s',
'4. 激活: tanh(...)',
'5. 映射: v^T·tanh(...)',
'6. Softmax归一化',
'7. 加权求和'
]
for i, step in enumerate(steps_bahdanau):
y = 0.75 - i * 0.1
ax1.text(0.1, y, step, fontsize=11, transform=ax1.transAxes,
bbox=dict(boxstyle='round', facecolor='lightblue', alpha=0.5))
ax1.axis('off')
# Scaled Dot-Product流程
ax2.text(0.5, 0.9, 'Scaled Dot-Product注意力', ha='center', fontsize=14,
fontweight='bold', transform=ax2.transAxes)
steps_scaled = [
'1. 矩阵乘法: Q·K^T',
'2. 缩放: score / √d_k',
'3. Softmax归一化',
'4. 加权求和: attn·V'
]
for i, step in enumerate(steps_scaled):
y = 0.75 - i * 0.1
ax2.text(0.1, y, step, fontsize=11, transform=ax2.transAxes,
bbox=dict(boxstyle='round', facecolor='lightgreen', alpha=0.5))
# 标注优势
ax2.text(0.5, 0.25, '✓ 计算步骤更少\n✓ 无额外参数\n✓ GPU加速友好',
ha='center', fontsize=12, transform=ax2.transAxes,
bbox=dict(boxstyle='round', facecolor='yellow', alpha=0.3))
ax2.axis('off')
plt.tight_layout()
plt.show()
compare_attention_mechanisms()
🏗️ 第三章：Transformer核心架构 - 层层剖析
3.1 完整的Transformer架构
class MultiHeadAttention(nn.Module):
"""多头注意力机制"""
def __init__(self, d_model, n_heads, dropout=0.1):
super().__init__()
assert d_model % n_heads == 0, "d_model必须能被n_heads整除"
self.d_model = d_model
self.n_heads = n_heads
self.d_k = d_model // n_heads
# Q, K, V线性变换
self.W_q = nn.Linear(d_model, d_model)
self.W_k = nn.Linear(d_model, d_model)
self.W_v = nn.Linear(d_model, d_model)
# 输出线性变换
self.W_o = nn.Linear(d_model, d_model)
# 注意力计算
self.attention = ScaledDotProductAttention(dropout)
self.dropout = nn.Dropout(dropout)
def forward(self, Q, K, V, mask=None):
"""
Args:
Q, K, V: [batch, seq_len, d_model]
mask: [batch, 1, seq_len] or [batch, seq_len, seq_len]
Returns:
output: [batch, seq_len, d_model]
attention: [batch, n_heads, seq_len, seq_len]
"""
batch_size = Q.size(0)
# 1. 线性变换并分割成多头
# [batch, seq_len, d_model] -> [batch, seq_len, n_heads, d_k]
Q = self.W_q(Q).view(batch_size, -1, self.n_heads, self.d_k)
K = self.W_k(K).view(batch_size, -1, self.n_heads, self.d_k)
V = self.W_v(V).view(batch_size, -1, self.n_heads, self.d_k)
# 转置以便多头并行计算
# [batch, n_heads, seq_len, d_k]
Q = Q.transpose(1, 2)
K = K.transpose(1, 2)
V = V.transpose(1, 2)
# 2. 计算注意力
if mask is not None:
mask = mask.unsqueeze(1) # [batch, 1, seq_len, seq_len]
x, attention = self.attention(Q, K, V, mask)
# 3. 拼接多头
# [batch, n_heads, seq_len, d_k] -> [batch, seq_len, n_heads, d_k]
x = x.transpose(1, 2).contiguous()
# [batch, seq_len, n_heads, d_k] -> [batch, seq_len, d_model]
x = x.view(batch_size, -1, self.d_model)
# 4. 最终线性变换
output = self.W_o(x)
return output, attention
class PositionwiseFeedForward(nn.Module):
"""位置前馈网络（FFN）"""
def __init__(self, d_model, d_ff, dropout=0.1):
super().__init__()
self.linear1 = nn.Linear(d_model, d_ff)
self.linear2 = nn.Linear(d_ff, d_model)
self.dropout = nn.Dropout(dropout)
def forward(self, x):
"""
FFN(x) = max(0, x·W_1 + b_1)·W_2 + b_2
Args:
x: [batch, seq_len, d_model]
Returns:
output: [batch, seq_len, d_model]
"""
# [batch, seq_len, d_model] -> [batch, seq_len, d_ff]
x = self.linear1(x)
x = F.relu(x)
x = self.dropout(x)
# [batch, seq_len, d_ff] -> [batch, seq_len, d_model]
x = self.linear2(x)
return x
class EncoderLayer(nn.Module):
"""Transformer编码器层"""
def __init__(self, d_model, n_heads, d_ff, dropout=0.1):
super().__init__()
# 多头自注意力
self.self_attention = MultiHeadAttention(d_model, n_heads, dropout)
# 前馈网络
self.feed_forward = PositionwiseFeedForward(d_model, d_ff, dropout)
# 层归一化
self.norm1 = nn.LayerNorm(d_model)
self.norm2 = nn.LayerNorm(d_model)
# Dropout
self.dropout = nn.Dropout(dropout)
def forward(self, x, mask=None):
"""
Args:
x: [batch, seq_len, d_model]
mask: [batch, 1, seq_len]
Returns:
output: [batch, seq_len, d_model]
attention: [batch, n_heads, seq_len, seq_len]
"""
# 1. 多头自注意力 + 残差连接 + 层归一化
attn_output, attention = self.self_attention(x, x, x, mask)
x = self.norm1(x + self.dropout(attn_output))
# 2. 前馈网络 + 残差连接 + 层归一化
ff_output = self.feed_forward(x)
x = self.norm2(x + self.dropout(ff_output))
return x, attention
class DecoderLayer(nn.Module):
"""Transformer解码器层"""
def __init__(self, d_model, n_heads, d_ff, dropout=0.1):
super().__init__()
# 掩码多头自注意力
self.self_attention = MultiHeadAttention(d_model, n_heads, dropout)
# 编码器-解码器注意力
self.cross_attention = MultiHeadAttention(d_model, n_heads, dropout)
# 前馈网络
self.feed_forward = PositionwiseFeedForward(d_model, d_ff, dropout)
# 层归一化
self.norm1 = nn.LayerNorm(d_model)
self.norm2 = nn.LayerNorm(d_model)
self.norm3 = nn.LayerNorm(d_model)
# Dropout
self.dropout = nn.Dropout(dropout)
def forward(self, x, encoder_output, src_mask=None, tgt_mask=None):
"""
Args:
x: [batch, tgt_len, d_model] 解码器输入
encoder_output: [batch, src_len, d_model] 编码器输出
src_mask: [batch, 1, src_len] 源序列掩码
tgt_mask: [batch, tgt_len, tgt_len] 目标序列掩码（因果掩码）
Returns:
output: [batch, tgt_len, d_model]
self_attn: 自注意力权重
cross_attn: 交叉注意力权重
"""
# 1. 掩码自注意力
self_attn_output, self_attn = self.self_attention(x, x, x, tgt_mask)
x = self.norm1(x + self.dropout(self_attn_output))
# 2. 编码器-解码器注意力
cross_attn_output, cross_attn = self.cross_attention(
x, encoder_output, encoder_output, src_mask
)
x = self.norm2(x + self.dropout(cross_attn_output))
# 3. 前馈网络
ff_output = self.feed_forward(x)
x = self.norm3(x + self.dropout(ff_output))
return x, self_attn, cross_attn
print("\n实验6：Transformer编码器层详细剖析\n")
# 创建编码器层
d_model = 512
n_heads = 8
d_ff = 2048
dropout = 0.1
encoder_layer = EncoderLayer(d_model, n_heads, d_ff, dropout)
# 测试输入
batch_size = 2
seq_len = 10
x = torch.randn(batch_size, seq_len, d_model)
# 前向传播
output, attention = encoder_layer(x)
print(f"输入形状: {x.shape}")
print(f"输出形状: {output.shape}")
print(f"注意力权重形状: {attention.shape}")
print(f" - [batch_size, n_heads, seq_len, seq_len]\n")
# 分析参数量
total_params = sum(p.numel() for p in encoder_layer.parameters())
print(f"编码器层总参数量: {total_params:,}")
# 详细分解
print("\n参数分解：")
mha_params = sum(p.numel() for p in encoder_layer.self_attention.parameters())
ffn_params = sum(p.numel() for p in encoder_layer.feed_forward.parameters())
ln_params = sum(p.numel() for p in encoder_layer.norm1.parameters()) + \
sum(p.numel() for p in encoder_layer.norm2.parameters())
print(f" - 多头注意力: {mha_params:,} ({mha_params/total_params*100:.1f}%)")
print(f" - 前馈网络: {ffn_params:,} ({ffn_params/total_params*100:.1f}%)")
print(f" - 层归一化: {ln_params:,} ({ln_params/total_params*100:.1f}%)\n")
# 可视化信息流
fig, axes = plt.subplots(2, 2, figsize=(14, 10))
# 1. 输入数据
axes[0, 0].imshow(x[0].detach().numpy().T, aspect='auto', cmap='viridis')
axes[0, 0].set_title('输入嵌入 [seq_len, d_model]', fontweight='bold')
axes[0, 0].set_xlabel('序列位置')
axes[0, 0].set_ylabel('嵌入维度')
# 2. 注意力权重（第一个头）
axes[0, 1].imshow(attention[0, 0].detach().numpy(), cmap='YlOrRd')
axes[0, 1].set_title('注意力权重（Head 1）', fontweight='bold')
axes[0, 1].set_xlabel('Key位置')
axes[0, 1].set_ylabel('Query位置')
# 3. 所有头的平均注意力
avg_attention = attention[0].mean(dim=0).detach().numpy()
axes[1, 0].imshow(avg_attention, cmap='Blues')
axes[1, 0].set_title('平均注意力权重（8个头）', fontweight='bold')
axes[1, 0].set_xlabel('Key位置')
axes[1, 0].set_ylabel('Query位置')
# 4. 输出数据
axes[1, 1].imshow(output[0].detach().numpy().T, aspect='auto', cmap='viridis')
axes[1, 1].set_title('输出表示 [seq_len, d_model]', fontweight='bold')
axes[1, 1].set_xlabel('序列位置')
axes[1, 1].set_ylabel('嵌入维度')
plt.tight_layout()
plt.show()
print("关键设计要点：")
print(" ✓ 残差连接：缓解梯度消失，使深层网络训练稳定")
print(" ✓ 层归一化：加速收敛，稳定训练过程")
print(" ✓ 多头注意力：捕获不同子空间的关系")
print(" ✓ FFN：为每个位置独立添加非线性变换\n")
3.2 完整的Transformer模型
class PositionalEncoding(nn.Module):
"""位置编码"""
def __init__(self, d_model, max_len=5000, dropout=0.1):
super().__init__()
self.dropout = nn.Dropout(dropout)
# 创建位置编码矩阵
pe = torch.zeros(max_len, d_model)
position = torch.arange(0, max_len, dtype=torch.float).unsqueeze(1)
div_term = torch.exp(
torch.arange(0, d_model, 2).float() *
(-math.log(10000.0) / d_model)
)
pe[:, 0::2] = torch.sin(position * div_term)
pe[:, 1::2] = torch.cos(position * div_term)
pe = pe.unsqueeze(0) # [1, max_len, d_model]
# 注册为buffer（不参与训练）
self.register_buffer('pe', pe)
def forward(self, x):
"""
Args:
x: [batch, seq_len, d_model]
Returns:
output: [batch, seq_len, d_model]
"""
x = x + self.pe[:, :x.size(1), :]
return self.dropout(x)
class Transformer(nn.Module):
"""完整的Transformer模型"""
def __init__(
self,
src_vocab_size,
tgt_vocab_size,
d_model=512,
n_heads=8,
n_encoder_layers=6,
n_decoder_layers=6,
d_ff=2048,
dropout=0.1,
max_len=5000
):
super().__init__()
# 嵌入层
self.src_embedding = nn.Embedding(src_vocab_size, d_model)
self.tgt_embedding = nn.Embedding(tgt_vocab_size, d_model)
# 位置编码
self.pos_encoding = PositionalEncoding(d_model, max_len, dropout)
# 编码器
self.encoder_layers = nn.ModuleList([
EncoderLayer(d_model, n_heads, d_ff, dropout)
for _ in range(n_encoder_layers)
])
# 解码器
self.decoder_layers = nn.ModuleList([
DecoderLayer(d_model, n_heads, d_ff, dropout)
for _ in range(n_decoder_layers)
])
# 输出层
self.fc_out = nn.Linear(d_model, tgt_vocab_size)
self.dropout = nn.Dropout(dropout)
# 初始化参数
self._init_parameters()
def _init_parameters(self):
"""参数初始化"""
for p in self.parameters():
if p.dim() > 1:
nn.init.xavier_uniform_(p)
def make_src_mask(self, src):
"""创建源序列掩码（填充掩码）"""
# src: [batch, src_len]
src_mask = (src != 0).unsqueeze(1).unsqueeze(2)
# [batch, 1, 1, src_len]
return src_mask
def make_tgt_mask(self, tgt):
"""创建目标序列掩码（因果掩码 + 填充掩码）"""
# tgt: [batch, tgt_len]
batch_size, tgt_len = tgt.shape
# 填充掩码
tgt_pad_mask = (tgt != 0).unsqueeze(1).unsqueeze(2)
# [batch, 1, 1, tgt_len]
# 因果掩码（下三角矩阵）
tgt_sub_mask = torch.tril(
torch.ones((tgt_len, tgt_len), device=tgt.device)
).bool()
# [tgt_len, tgt_len]
# 合并掩码
tgt_mask = tgt_pad_mask & tgt_sub_mask
# [batch, 1, tgt_len, tgt_len]
return tgt_mask
def encode(self, src, src_mask):
"""编码器前向传播"""
# 嵌入 + 位置编码
x = self.src_embedding(src) * math.sqrt(self.src_embedding.embedding_dim)
x = self.pos_encoding(x)
# 通过所有编码器层
encoder_attentions = []
for layer in self.encoder_layers:
x, attention = layer(x, src_mask)
encoder_attentions.append(attention)
return x, encoder_attentions
def decode(self, tgt, encoder_output, src_mask, tgt_mask):
"""解码器前向传播"""
# 嵌入 + 位置编码
x = self.tgt_embedding(tgt) * math.sqrt(self.tgt_embedding.embedding_dim)
x = self.pos_encoding(x)
# 通过所有解码器层
decoder_self_attentions = []
decoder_cross_attentions = []
for layer in self.decoder_layers:
x, self_attn, cross_attn = layer(x, encoder_output, src_mask, tgt_mask)
decoder_self_attentions.append(self_attn)
decoder_cross_attentions.append(cross_attn)
return x, decoder_self_attentions, decoder_cross_attentions
def forward(self, src, tgt):
"""
Args:
src: [batch, src_len]
tgt: [batch, tgt_len]
Returns:
output: [batch, tgt_len, tgt_vocab_size]
attentions: 所有注意力权重
"""
# 创建掩码
src_mask = self.make_src_mask(src)
tgt_mask = self.make_tgt_mask(tgt)
# 编码
encoder_output, enc_attns = self.encode(src, src_mask)
# 解码
decoder_output, dec_self_attns, dec_cross_attns = self.decode(
tgt, encoder_output, src_mask, tgt_mask
)
# 输出投影
output = self.fc_out(decoder_output)
attentions = {
'encoder': enc_attns,
'decoder_self': dec_self_attns,
'decoder_cross': dec_cross_attns
}
return output, attentions
print("\n实验7：完整Transformer模型构建\n")
# 创建Transformer
src_vocab_size = 10000
tgt_vocab_size = 10000
transformer = Transformer(
src_vocab_size=src_vocab_size,
tgt_vocab_size=tgt_vocab_size,
d_model=512,
n_heads=8,
n_encoder_layers=6,
n_decoder_layers=6,
d_ff=2048,
dropout=0.1
)
# 模拟输入
src = torch.randint(1, src_vocab_size, (2, 20)) # [batch=2, src_len=20]
tgt = torch.randint(1, tgt_vocab_size, (2, 15)) # [batch=2, tgt_len=15]
print(f"源序列形状: {src.shape}")
print(f"目标序列形状: {tgt.shape}\n")
# 前向传播
output, attentions = transformer(src, tgt)
print(f"输出形状: {output.shape}")
print(f" - [batch_size, tgt_len, tgt_vocab_size]\n")
# 统计参数
total_params = sum(p.numel() for p in transformer.parameters())
trainable_params = sum(p.numel() for p in transformer.parameters() if p.requires_grad)
print(f"总参数量: {total_params:,}")
print(f"可训练参数: {trainable_params:,}\n")
# 详细分解
print("参数分布：")
embedding_params = sum(p.numel() for p in transformer.src_embedding.parameters()) + \
sum(p.numel() for p in transformer.tgt_embedding.parameters())
encoder_params = sum(p.numel() for layer in transformer.encoder_layers
for p in layer.parameters())
decoder_params = sum(p.numel() for layer in transformer.decoder_layers
for p in layer.parameters())
output_params = sum(p.numel() for p in transformer.fc_out.parameters())
print(f" 嵌入层: {embedding_params:,} ({embedding_params/total_params*100:.1f}%)")
print(f" 编码器: {encoder_params:,} ({encoder_params/total_params*100:.1f}%)")
print(f" 解码器: {decoder_params:,} ({decoder_params/total_params*100:.1f}%)")
print(f" 输出层: {output_params:,} ({output_params/total_params*100:.1f}%)\n")
# 可视化架构
fig, axes = plt.subplots(1, 3, figsize=(18, 8))
# 编码器注意力（第一层）
enc_attn = attentions['encoder'][0][0, 0].detach().numpy() # [seq_len, seq_len]
im1 = axes[0].imshow(enc_attn, cmap='Blues', aspect='auto')
axes[0].set_title('编码器自注意力（Layer 1, Head 1）', fontweight='bold')
axes[0].set_xlabel('Key位置')
axes[0].set_ylabel('Query位置')
plt.colorbar(im1, ax=axes[0], label='注意力权重')
# 解码器自注意力（第一层）
dec_self_attn = attentions['decoder_self'][0][0, 0].detach().numpy()
im2 = axes[1].imshow(dec_self_attn, cmap='Greens', aspect='auto')
axes[1].set_title('解码器自注意力（因果掩码）', fontweight='bold')
axes[1].set_xlabel('Key位置')
axes[1].set_ylabel('Query位置')
plt.colorbar(im2, ax=axes[1], label='注意力权重')
# 解码器交叉注意力（第一层）
dec_cross_attn = attentions['decoder_cross'][0][0, 0].detach().numpy()
im3 = axes[2].imshow(dec_cross_attn, cmap='Reds', aspect='auto')
axes[2].set_title('解码器交叉注意力（编码器-解码器）', fontweight='bold')
axes[2].set_xlabel('编码器Key位置')
axes[2].set_ylabel('解码器Query位置')
plt.colorbar(im3, ax=axes[2], label='注意力权重')
plt.tight_layout()
plt.show()
print("架构特点总结：")
print(" ✓ 编码器：双向自注意力，捕获全局上下文")
print(" ✓ 解码器：因果自注意力，防止未来信息泄漏")
print(" ✓ 交叉注意力：对齐源序列和目标序列")
print(" ✓ 6层堆叠：逐步抽象特征表示\n")
📍 第四章：位置编码 - 序列信息的艺术
4.1 为什么需要位置编码？
def demonstrate_position_importance():
"""演示位置信息的重要性"""
print("\n实验8：位置编码的必要性\n")
# 两个语义完全不同的句子（词序不同）
sentence1 = "The dog bit the man"
sentence2 = "The man bit the dog"
print("示例句子：")
print(f" 句子1: {sentence1}")
print(f" 句子2: {sentence2}")
print(f" 词汇相同，但语义完全相反！\n")
# 模拟词袋模型（无位置信息）
from collections import Counter
words1 = sentence1.lower().split()
words2 = sentence2.lower().split()
bow1 = Counter(words1)
bow2 = Counter(words2)
print("词袋表示（Bag of Words）：")
print(f" 句子1: {dict(bow1)}")
print(f" 句子2: {dict(bow2)}")
print(f" 结果：完全相同！❌\n")
print("⚠️ 问题：自注意力机制本身是置换不变的")
print(" 即：Attention(x_1, x_2, x_3) = Attention(x_2, x_1, x_3)")
print(" 解决：必须注入位置信息！\n")
demonstrate_position_importance()
4.2 正弦位置编码详解
class PositionalEncodingAnalyzer:
"""位置编码分析器"""
def __init__(self, d_model=512, max_len=100):
self.d_model = d_model
self.max_len = max_len
# 生成位置编码矩阵
self.pe = self.create_positional_encoding()
def create_positional_encoding(self):
"""创建正弦位置编码"""
pe = torch.zeros(self.max_len, self.d_model)
position = torch.arange(0, self.max_len, dtype=torch.float).unsqueeze(1)
div_term = torch.exp(
torch.arange(0, self.d_model, 2).float() *
(-math.log(10000.0) / self.d_model)
)
# PE(pos, 2i) = sin(pos / 10000^(2i/d_model))
pe[:, 0::2] = torch.sin(position * div_term)
# PE(pos, 2i+1) = cos(pos / 10000^(2i/d_model))
pe[:, 1::2] = torch.cos(position * div_term)
return pe
def visualize_encoding(self):
"""可视化位置编码"""
fig, axes = plt.subplots(2, 2, figsize=(16, 10))
# 1. 完整位置编码矩阵
im1 = axes[0, 0].imshow(
self.pe.numpy().T,
cmap='RdBu',
aspect='auto',
extent=[0, self.max_len, 0, self.d_model]
)
axes[0, 0].set_xlabel('位置', fontsize=12)
axes[0, 0].set_ylabel('嵌入维度', fontsize=12)
axes[0, 0].set_title('位置编码矩阵 [max_len, d_model]',
fontsize=14, fontweight='bold')
plt.colorbar(im1, ax=axes[0, 0])
# 2. 不同位置的编码向量
positions = [0, 10, 50, 99]
for pos in positions:
axes[0, 1].plot(
self.pe[pos, :64].numpy(), # 只显示前64维
label=f'位置 {pos}',
linewidth=2,
alpha=0.7
)
axes[0, 1].set_xlabel('维度索引', fontsize=12)
axes[0, 1].set_ylabel('编码值', fontsize=12)
axes[0, 1].set_title('不同位置的编码向量（前64维）',
fontsize=14, fontweight='bold')
axes[0, 1].legend()
axes[0, 1].grid(True, alpha=0.3)
# 3. 不同维度的频率
dims = [0, 10, 100, 500]
x = np.arange(self.max_len)
for dim in dims:
axes[1, 0].plot(
x,
self.pe[:, dim].numpy(),
label=f'维度 {dim}',
linewidth=2,
alpha=0.7
)
axes[1, 0].set_xlabel('位置', fontsize=12)
axes[1, 0].set_ylabel('编码值', fontsize=12)
axes[1, 0].set_title('不同维度的周期性模式',
fontsize=14, fontweight='bold')
axes[1, 0].legend()
axes[1, 0].grid(True, alpha=0.3)
# 4. 相对位置的内积（相似度）
# 计算位置0与其他位置的余弦相似度
pos_0 = self.pe[0].unsqueeze(0)
similarities = F.cosine_similarity(
pos_0.repeat(self.max_len, 1),
self.pe,
dim=1
).numpy()
axes[1, 1].plot(x, similarities, linewidth=2.5, color='purple')
axes[1, 1].set_xlabel('相对位置', fontsize=12)
axes[1, 1].set_ylabel('余弦相似度', fontsize=12)
axes[1, 1].set_title('位置0与其他位置的相似度',
fontsize=14, fontweight='bold')
axes[1, 1].grid(True, alpha=0.3)
axes[1, 1].axhline(y=0, color='red', linestyle='--', alpha=0.5)
plt.tight_layout()
plt.show()
def analyze_properties(self):
"""分析位置编码性质"""
print("\n实验9：正弦位置编码性质分析\n")
# 1. 唯一性
print("1. 唯一性验证：")
unique_encodings = torch.unique(self.pe, dim=0).shape[0]
print(f" 不同的位置编码数: {unique_encodings}")
print(f" 总位置数: {self.max_len}")
print(f" 是否唯一: {'✅' if unique_encodings == self.max_len else '❌'}\n")
# 2. 相对位置线性性
print("2. 相对位置线性性：")
print(" 理论：PE(pos+k) 可以表示为 PE(pos) 的线性函数")
k = 5
pos = 10
# 计算PE(pos+k) 和 PE(pos)的相似度
similarity = F.cosine_similarity(
self.pe[pos].unsqueeze(0),
self.pe[pos+k].unsqueeze(0)
).item()
print(f" PE({pos}) 与 PE({pos+k}) 的余弦相似度: {similarity:.4f}")
print(f" 含义：位置 {pos} 和 {pos+k} 有一定关系，但不完全相同\n")
# 3. 外推能力
print("3. 外推能力测试：")
print(" 正弦编码可以推广到未见过的序列长度")
extended_pe = self.create_extended_encoding(self.max_len + 50)
print(f" 原始最大长度: {self.max_len}")
print(f" 扩展后长度: {extended_pe.shape[0]}")
print(f" 编码维度保持: {extended_pe.shape[1]} = {self.d_model} ✅\n")
# 4. 频率分布
print("4. 频率分布：")
print(" 低维度：高频变化（局部位置信息）")
print(" 高维度：低频变化（全局位置信息）")
# 计算不同维度的周期
for dim in [0, 128, 256, 384, 510]:
# 找到第一个周期（近似）
signal = self.pe[:, dim].numpy()
peaks = np.where(np.diff(np.sign(np.diff(signal))) < 0)[0] + 1
if len(peaks) > 1:
period = peaks[1] - peaks[0]
print(f" 维度 {dim:3d}: 周期 ≈ {period:3d} 个位置")
print()
def create_extended_encoding(self, new_max_len):
"""创建扩展的位置编码"""
pe = torch.zeros(new_max_len, self.d_model)
position = torch.arange(0, new_max_len, dtype=torch.float).unsqueeze(1)
div_term = torch.exp(
torch.arange(0, self.d_model, 2).float() *
(-math.log(10000.0) / self.d_model)
)
pe[:, 0::2] = torch.sin(position * div_term)
pe[:, 1::2] = torch.cos(position * div_term)
return pe
# 运行分析
pe_analyzer = PositionalEncodingAnalyzer(d_model=512, max_len=100)
pe_analyzer.visualize_encoding()
pe_analyzer.analyze_properties()
print("关键洞察：")
print(" ✓ 每个位置有唯一的编码向量")
print(" ✓ 相对位置关系通过向量运算可学习")
print(" ✓ 可以外推到训练时未见过的长度")
print(" ✓ 多尺度频率捕获局部和全局信息\n")
4.3 可学习位置编码 vs 固定位置编码
class LearnablePositionalEncoding(nn.Module):
"""可学习的位置编码"""
def __init__(self, d_model, max_len=5000, dropout=0.1):
super().__init__()
self.dropout = nn.Dropout(dropout)
# 可学习的位置嵌入
self.position_embeddings = nn.Embedding(max_len, d_model)
def forward(self, x):
"""
Args:
x: [batch, seq_len, d_model]
"""
batch_size, seq_len, _ = x.shape
positions = torch.arange(0, seq_len, device=x.device).unsqueeze(0)
positions = positions.expand(batch_size, seq_len)
pos_embeddings = self.position_embeddings(positions)
x = x + pos_embeddings
return self.dropout(x)
def compare_positional_encodings():
"""对比不同位置编码方案"""
print("\n实验10：固定位置编码 vs 可学习位置编码\n")
d_model = 128
max_len = 50
# 固定位置编码
fixed_pe = PositionalEncoding(d_model, max_len)
# 可学习位置编码
learnable_pe = LearnablePositionalEncoding(d_model, max_len)
# 创建测试输入
x = torch.randn(4, max_len, d_model)
# 应用编码
x_fixed = fixed_pe(x.clone())
x_learnable = learnable_pe(x.clone())
print(f"输入形状: {x.shape}")
print(f"固定编码输出: {x_fixed.shape}")
print(f"可学习编码输出: {x_learnable.shape}\n")
# 对比
comparison = {
'固定正弦编码': {
'参数量': 0,
'外推能力': '✅ 可外推到更长序列',
'初始化': '数学公式定义',
'训练': '不参与训练',
'代表模型': 'Transformer (Vaswani 2017)'
},
'可学习编码': {
'参数量': d_model * max_len,
'外推能力': '❌ 受max_len限制',
'初始化': '随机初始化',
'训练': '反向传播学习',
'代表模型': 'BERT, GPT'
}
}
print("="*80)
print(f"{'方法':<15} {'参数量':<15} {'外推能力':<25} {'代表模型':<20}")
print("="*80)
for method, props in comparison.items():
print(f"{method:<15} {str(props['参数量']):<15} "
f"{props['外推能力']:<25} {props['代表模型']:<20}")
print("="*80)
print()
# 可视化对比
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 5))
# 固定编码的模式
fixed_pattern = fixed_pe.pe[0, :max_len, :64].detach().numpy().T
im1 = ax1.imshow(fixed_pattern, aspect='auto', cmap='coolwarm')
ax1.set_title('固定正弦编码（前64维）', fontsize=13, fontweight='bold')
ax1.set_xlabel('位置')
ax1.set_ylabel('维度')
plt.colorbar(im1, ax=ax1)
# 可学习编码的初始模式
with torch.no_grad():
positions = torch.arange(0, max_len).unsqueeze(0)
learnable_pattern = learnable_pe.position_embeddings(positions)[0, :, :64].numpy().T
im2 = ax2.imshow(learnable_pattern, aspect='auto', cmap='coolwarm')
ax2.set_title('可学习编码（初始化，前64维）', fontsize=13, fontweight='bold')
ax2.set_xlabel('位置')
ax2.set_ylabel('维度')
plt.colorbar(im2, ax=ax2)
plt.tight_layout()
plt.show()
print("选择建议：")
print(" • 固定编码：适合需要外推的任务（如长文本生成）")
print(" • 可学习编码：适合固定长度任务（如分类、NER）")
print(" • 实践中：两者性能差异不大，BERT等大模型多用可学习编码\n")
compare_positional_encodings()
🎯 第五章：多头注意力 - 并行的智慧
5.1 为什么需要多头？
def visualize_multi_head_concept():
"""可视化多头注意力的核心概念"""
print("\n实验11：多头注意力的直觉理解\n")
# 类比：多个专家从不同角度看问题
sentence = "The bank can guarantee deposits will eventually cover future tuition costs"
print("示例句子：")
print(f" '{sentence}'\n")
print("单头注意力的局限：")
print(" 只能学习一种关系模式")
print(" 例如：可能只关注句法关系（主谓宾）\n")
print("多头注意力的优势：")
heads_focus = {
'Head 1 (句法)': ['bank → can', 'deposits → cover', 'costs → tuition'],
'Head 2 (语义)': ['bank → deposits', 'guarantee → cover', 'future → eventually'],
'Head 3 (共指)': ['deposits → costs', 'will → eventually'],
'Head 4 (位置)': ['相邻词关系', '远距离依赖']
}
for head, relations in heads_focus.items():
print(f" {head}:")
for rel in relations:
print(f" - {rel}")
print("\n核心思想：不同头学习不同的注意力模式！\n")
class MultiHeadAttentionVisualizer:
"""多头注意力可视化工具"""
def __init__(self, d_model=512, n_heads=8):
self.d_model = d_model
self.n_heads = n_heads
self.d_k = d_model // n_heads
# 创建多头注意力层
self.mha = MultiHeadAttention(d_model, n_heads)
def analyze_head_specialization(self):
"""分析不同头的专业化"""
print("\n实验12：注意力头的专业化分析\n")
# 创建模拟句子
batch_size = 1
seq_len = 12
x = torch.randn(batch_size, seq_len, self.d_model)
# 前向传播
output, attention = self.mha(x, x, x)
# 分析每个头的注意力分布
attention_np = attention[0].detach().numpy() # [n_heads, seq_len, seq_len]
fig, axes = plt.subplots(2, 4, figsize=(20, 10))
axes = axes.flatten()
words = ['The', 'cat', 'sat', 'on', 'the', 'mat', 'and',
'watched', 'the', 'dog', 'play', '.']
for head_idx in range(self.n_heads):
ax = axes[head_idx]
# 绘制注意力热图
im = ax.imshow(attention_np[head_idx], cmap='YlOrRd', vmin=0, vmax=1)
ax.set_xticks(range(seq_len))
ax.set_yticks(range(seq_len))
ax.set_xticklabels(words, rotation=45, ha='right', fontsize=9)
ax.set_yticklabels(words, fontsize=9)
ax.set_title(f'Head {head_idx + 1}', fontweight='bold', fontsize=12)
# 添加颜色条
plt.colorbar(im, ax=ax, fraction=0.046, pad=0.04)
plt.tight_layout()
plt.show()
# 计算每个头的统计特性
print("各头注意力模式分析：\n")
for head_idx in range(self.n_heads):
head_attn = attention_np[head_idx]
# 对角线权重（关注自身）
diagonal_weight = np.mean(np.diag(head_attn))
# 局部性（关注相邻词）
local_weight = 0
for i in range(seq_len):
if i > 0:
local_weight += head_attn[i, i-1]
if i < seq_len - 1:
local_weight += head_attn[i, i+1]
local_weight /= (2 * seq_len - 2)
# 全局性（关注远距离）
global_weight = 0
count = 0
for i in range(seq_len):
for j in range(seq_len):
if abs(i - j) > 3:
global_weight += head_attn[i, j]
count += 1
global_weight /= count if count > 0 else 1
print(f"Head {head_idx + 1}:")
print(f" 自注意权重: {diagonal_weight:.3f}")
print(f" 局部权重: {local_weight:.3f}")
print(f" 全局权重: {global_weight:.3f}")
# 判断模式
if diagonal_weight > 0.3:
pattern = "自关注型"
elif local_weight > global_weight:
pattern = "局部型"
else:
pattern = "全局型"
print(f" 模式类型: {pattern}\n")
def visualize_head_projection(self):
"""可视化头的投影空间分割"""
print("\n实验13：多头如何分割特征空间\n")
print(f"模型维度 d_model: {self.d_model}")
print(f"注意力头数 n_heads: {self.n_heads}")
print(f"每头维度 d_k: {self.d_k}\n")
# 可视化维度分割
fig, ax = plt.subplots(figsize=(14, 4))
colors = plt.cm.Set3(range(self.n_heads))
for head_idx in range(self.n_heads):
start = head_idx * self.d_k
end = (head_idx + 1) * self.d_k
ax.barh(0, self.d_k, left=start, height=0.8,
color=colors[head_idx], edgecolor='black', linewidth=2,
label=f'Head {head_idx + 1}')
# 标注维度范围
ax.text(start + self.d_k/2, 0, f'{start}-{end}',
ha='center', va='center', fontsize=10, fontweight='bold')
ax.set_xlim(0, self.d_model)
ax.set_ylim(-0.5, 0.5)
ax.set_xlabel('特征维度', fontsize=12)
ax.set_title(f'多头注意力特征空间分割（{self.n_heads}个头）',
fontsize=14, fontweight='bold')
ax.set_yticks([])
ax.legend(loc='upper left', bbox_to_anchor=(1, 1), ncol=1)
plt.tight_layout()
plt.show()
print("关键机制：")
print(f" 1. 输入 x ∈ R^{self.d_model} 被投影到 {self.n_heads} 个子空间")
print(f" 2. 每个子空间维度为 d_k = {self.d_k}")
print(f" 3. 各头独立计算注意力，学习不同模式")
print(f" 4. 最后拼接并线性变换回 R^{self.d_model}\n")
# 展示计算流程
print("数学公式：")
print(" MultiHead(Q, K, V) = Concat(head₁, ..., head₈)·W^O")
print(" 其中：")
print(" head_i = Attention(Q·W^Q_i, K·W^K_i, V·W^V_i)")
print(f" W^Q_i, W^K_i, W^V_i ∈ R^({self.d_model}×{self.d_k})")
print(f" W^O ∈ R^({self.d_model}×{self.d_model})\n")
visualize_multi_head_concept()
mha_viz = MultiHeadAttentionVisualizer(d_model=512, n_heads=8)
mha_viz.analyze_head_specialization()
mha_viz.visualize_head_projection()
5.2 多头注意力的计算效率
class MultiHeadEfficiencyAnalyzer:
"""多头注意力效率分析"""
def __init__(self):
pass
def compare_implementations(self):
"""对比不同实现方式"""
print("\n实验14：多头注意力的高效实现\n")
d_model = 512
n_heads = 8
batch_size = 32
seq_len = 128
# 方案1：循环实现（低效）
print("方案1：循环计算每个头（朴素实现）")
print(" for head in range(n_heads):")
print(" head_output = attention(Q_head, K_head, V_head)")
print(" 缺点：无法并行，GPU利用率低\n")
# 方案2：批量并行实现（高效）
print("方案2：批量并行计算（实际使用）")
print(" Q, K, V reshape: [batch, seq_len, n_heads, d_k]")
print(" transpose: [batch, n_heads, seq_len, d_k]")
print(" 批量矩阵乘法：所有头同时计算")
print(" 优点：充分利用GPU并行能力\n")
# 性能对比
device = 'cuda' if torch.cuda.is_available() else 'cpu'
# 创建测试数据
Q = torch.randn(batch_size, seq_len, d_model, device=device)
K = torch.randn(batch_size, seq_len, d_model, device=device)
V = torch.randn(batch_size, seq_len, d_model, device=device)
# 创建多头注意力层
mha = MultiHeadAttention(d_model, n_heads).to(device)
# 预热
with torch.no_grad():
for _ in range(10):
_ = mha(Q, K, V)
# 计时
import time
n_runs = 100
torch.cuda.synchronize() if torch.cuda.is_available() else None
start = time.time()
with torch.no_grad():
for _ in range(n_runs):
output, _ = mha(Q, K, V)
torch.cuda.synchronize() if torch.cuda.is_available() else None
end = time.time()
avg_time = (end - start) / n_runs * 1000 # 转换为毫秒
print(f"性能测试结果（{device.upper()}）：")
print(f" 批次大小: {batch_size}")
print(f" 序列长度: {seq_len}")
print(f" 平均时间: {avg_time:.2f} ms")
print(f" 吞吐量: {batch_size * seq_len / avg_time * 1000:.0f} tokens/s\n")
# FLOPs分析
print("计算复杂度分析：")
# Q·K^T
qk_flops = batch_size * n_heads * seq_len * seq_len * (d_model // n_heads)
# softmax(QK^T)·V
sv_flops = batch_size * n_heads * seq_len * seq_len * (d_model // n_heads)
# 线性投影（Q, K, V, O）
proj_flops = 4 * batch_size * seq_len * d_model * d_model
total_flops = qk_flops + sv_flops + proj_flops
print(f" QK^T计算: {qk_flops / 1e9:.2f} GFLOPs")
print(f" Softmax·V: {sv_flops / 1e9:.2f} GFLOPs")
print(f" 线性投影: {proj_flops / 1e9:.2f} GFLOPs")
print(f" 总计: {total_flops / 1e9:.2f} GFLOPs\n")
# 内存占用
print("内存占用分析：")
# 输入
input_mem = 3 * batch_size * seq_len * d_model * 4 / 1024**2 # float32
# 注意力矩阵
attn_mem = batch_size * n_heads * seq_len * seq_len * 4 / 1024**2
# 权重矩阵
weight_mem = 4 * d_model * d_model * 4 / 1024**2
total_mem = input_mem + attn_mem + weight_mem
print(f" 输入张量: {input_mem:.2f} MB")
print(f" 注意力矩阵: {attn_mem:.2f} MB")
print(f" 权重参数: {weight_mem:.2f} MB")
print(f" 总计: {total_mem:.2f} MB\n")
def visualize_bottleneck(self):
"""可视化计算瓶颈"""
seq_lengths = [64, 128, 256, 512, 1024, 2048]
d_model = 512
n_heads = 8
batch_size = 16
attn_flops = []
proj_flops = []
attn_mem = []
for seq_len in seq_lengths:
# 注意力计算
attn_f = 2 * batch_size * n_heads * seq_len**2 * (d_model // n_heads)
attn_flops.append(attn_f / 1e9)
# 投影计算
proj_f = 4 * batch_size * seq_len * d_model**2
proj_flops.append(proj_f / 1e9)
# 注意力矩阵内存
attn_m = batch_size * n_heads * seq_len**2 * 4 / 1024**2
attn_mem.append(attn_m)
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 5))
# FLOPs对比
x = np.arange(len(seq_lengths))
width = 0.35
ax1.bar(x - width/2, attn_flops, width, label='注意力计算 (O(n²d))',
color='coral', alpha=0.8)
ax1.bar(x + width/2, proj_flops, width, label='线性投影 (O(nd²))',
color='skyblue', alpha=0.8)
ax1.set_xlabel('序列长度', fontsize=12)
ax1.set_ylabel('计算量 (GFLOPs)', fontsize=12)
ax1.set_title('计算量随序列长度变化', fontsize=14, fontweight='bold')
ax1.set_xticks(x)
ax1.set_xticklabels(seq_lengths)
ax1.legend(fontsize=11)
ax1.grid(True, alpha=0.3, axis='y')
# 内存占用
ax2.plot(seq_lengths, attn_mem, marker='o', linewidth=2.5,
markersize=8, color='red', label='注意力矩阵')
ax2.fill_between(seq_lengths, attn_mem, alpha=0.3, color='red')
ax2.set_xlabel('序列长度', fontsize=12)
ax2.set_ylabel('内存占用 (MB)', fontsize=12)
ax2.set_title('注意力矩阵内存随序列长度变化', fontsize=14, fontweight='bold')
ax2.legend(fontsize=11)
ax2.grid(True, alpha=0.3)
ax2.set_yscale('log')
# 标注关键点
for i, (sl, mem) in enumerate(zip(seq_lengths, attn_mem)):
if sl in [512, 2048]:
ax2.annotate(f'{mem:.0f} MB',
xy=(sl, mem),
xytext=(10, 10),
textcoords='offset points',
fontsize=10,
bbox=dict(boxstyle='round', facecolor='yellow', alpha=0.5))
plt.tight_layout()
plt.show()
print("\n瓶颈分析：")
print(" ✓ 序列长度 < 512：线性投影是主要计算量")
print(" ✓ 序列长度 > 512：注意力计算（O(n²)）成为瓶颈")
print(" ✓ 长序列场景：注意力矩阵内存占用急剧增长")
print(" → 解决方案：稀疏注意力、线性注意力（第9章）\n")
analyzer = MultiHeadEfficiencyAnalyzer()
analyzer.compare_implementations()
analyzer.visualize_bottleneck()
🔗 第六章：前馈网络与残差连接 - 稳定性的基石
6.1 Position-wise Feed-Forward Network
class FFNAnalyzer:
"""前馈网络分析器"""
def __init__(self):
pass
def explain_ffn_role(self):
"""解释FFN的作用"""
print("\n实验15：前馈网络的作用\n")
print("FFN = Feed-Forward Network（位置前馈网络）\n")
print("定义：")
print(" FFN(x) = max(0, x·W₁ + b₁)·W₂ + b₂")
print(" 或者：")
print(" FFN(x) = ReLU(x·W₁ + b₁)·W₂ + b₂\n")
print("关键特点：")
print(" 1. Position-wise：对每个位置独立应用")
print(" 即：FFN(x[i]) 与其他位置无关")
print(" 2. 两层全连接网络")
print(" 第一层：d_model → d_ff (扩张，通常d_ff = 4×d_model)")
print(" 第二层：d_ff → d_model (收缩)")
print(" 3. ReLU激活函数引入非线性\n")
print("为什么需要FFN？")
print(" 问题：注意力机制本质是加权平均（线性操作）")
print(" 解决：FFN提供非线性变换能力")
print(" 类比：CNN中的1×1卷积 + 非线性激活\n")
def visualize_ffn_transformation(self):
"""可视化FFN的变换"""
print("\n实验16：FFN的特征变换可视化\n")
d_model = 512
d_ff = 2048
batch_size = 1
seq_len = 10
# 创建FFN
ffn = PositionwiseFeedForward(d_model, d_ff)
# 输入数据
x = torch.randn(batch_size, seq_len, d_model)
# 前向传播并记录中间值
with torch.no_grad():
# 第一层
hidden = ffn.linear1(x) # [batch, seq_len, d_ff]
hidden_activated = F.relu(hidden)
# 第二层
output = ffn.linear2(hidden_activated) # [batch, seq_len, d_model]
# 可视化
fig, axes = plt.subplots(2, 2, figsize=(14, 10))
# 输入
im1 = axes[0, 0].imshow(x[0].numpy().T, aspect='auto', cmap='viridis')
axes[0, 0].set_title(f'输入 [{seq_len}, {d_model}]', fontweight='bold')
axes[0, 0].set_xlabel('序列位置')
axes[0, 0].set_ylabel('特征维度')
plt.colorbar(im1, ax=axes[0, 0])
# 第一层输出（ReLU前）
im2 = axes[0, 1].imshow(hidden[0].numpy().T, aspect='auto', cmap='viridis')
axes[0, 1].set_title(f'第一层 [{seq_len}, {d_ff}] (ReLU前)', fontweight='bold')
axes[0, 1].set_xlabel('序列位置')
axes[0, 1].set_ylabel('特征维度')
plt.colorbar(im2, ax=axes[0, 1])
# 第一层输出（ReLU后）
im3 = axes[1, 0].imshow(hidden_activated[0].numpy().T, aspect='auto', cmap='viridis')
axes[1, 0].set_title(f'第一层 [{seq_len}, {d_ff}] (ReLU后)', fontweight='bold')
axes[1, 0].set_xlabel('序列位置')
axes[1, 0].set_ylabel('特征维度')
plt.colorbar(im3, ax=axes[1, 0])
# 输出
im4 = axes[1, 1].imshow(output[0].numpy().T, aspect='auto', cmap='viridis')
axes[1, 1].set_title(f'输出 [{seq_len}, {d_model}]', fontweight='bold')
axes[1, 1].set_xlabel('序列位置')
axes[1, 1].set_ylabel('特征维度')
plt.colorbar(im4, ax=axes[1, 1])
plt.tight_layout()
plt.show()
# 统计分析
print("ReLU的稀疏化效果：")
sparsity_before = (hidden[0] == 0).float().mean().item() * 100
sparsity_after = (hidden_activated[0] == 0).float().mean().item() * 100
print(f" ReLU前零元素比例: {sparsity_before:.2f}%")
print(f" ReLU后零元素比例: {sparsity_after:.2f}%")
print(f" 稀疏度提升: {sparsity_after - sparsity_before:.2f}%\n")
print("稀疏激活的好处：")
print(" ✓ 提高模型容量（神经元选择性激活）")
print(" ✓ 减少过拟合风险")
print(" ✓ 加速推理（可利用稀疏计算优化）\n")
ffn_analyzer = FFNAnalyzer()
ffn_analyzer.explain_ffn_role()
ffn_analyzer.visualize_ffn_transformation()
6.2 残差连接与层归一化
class ResidualConnectionAnalyzer:
"""残差连接分析器"""
def __init__(self):
pass
def explain_residual_connection(self):
"""解释残差连接"""
print("\n实验17：残差连接的重要性\n")
print("定义：")
print(" output = LayerNorm(x + Sublayer(x))")
print(" 其中 Sublayer 可以是：")
print(" - 多头注意力")
print(" - 前馈网络\n")
print("为什么需要残差连接？")
print(" 1. 缓解梯度消失问题")
print(" 反向传播时，梯度可以直接通过shortcut传递")
print(" 2. 允许更深的网络")
print(" 原始Transformer：6层编码器 + 6层解码器")
print(" GPT-3：96层！")
print(" 3. 加速训练收敛")
print(" 初始时，Sublayer(x) ≈ 0，网络从恒等映射开始学习\n")
def demonstrate_gradient_flow(self):
"""演示梯度流"""
print("\n实验18：残差连接的梯度流分析\n")
# 创建简单的网络：有残差 vs 无残差
class SimpleBlockWithResidual(nn.Module):
def __init__(self, dim):
super().__init__()
self.layer = nn.Linear(dim, dim)
self.norm = nn.LayerNorm(dim)
def forward(self, x):
return self.norm(x + self.layer(x))
class SimpleBlockWithoutResidual(nn.Module):
def __init__(self, dim):
super().__init__()
self.layer = nn.Linear(dim, dim)
self.norm = nn.LayerNorm(dim)
def forward(self, x):
return self.norm(self.layer(x))
# 堆叠多层
n_layers = 10
dim = 128
# 有残差
model_with_res = nn.Sequential(*[
SimpleBlockWithResidual(dim) for _ in range(n_layers)
])
# 无残差
model_without_res = nn.Sequential(*[
SimpleBlockWithoutResidual(dim) for _ in range(n_layers)
])
# 输入
x = torch.randn(1, 10, dim, requires_grad=True)
# 前向传播
out_with_res = model_with_res(x)
out_without_res = model_without_res(x.clone())
# 反向传播
loss_with_res = out_with_res.sum()
loss_without_res = out_without_res.sum()
loss_with_res.backward()
grad_with_res = x.grad.clone()
x.grad.zero_()
loss_without_res.backward()
grad_without_res = x.grad.clone()
# 比较梯度范数
grad_norm_with = grad_with_res.norm().item()
grad_norm_without = grad_without_res.norm().item()
print(f"梯度范数对比（{n_layers}层网络）：")
print(f" 有残差连接: {grad_norm_with:.4f}")
print(f" 无残差连接: {grad_norm_without:.4f}")
print(f" 差异: {grad_norm_with / grad_norm_without:.2f}×\n")
# 逐层梯度范数
print("逐层梯度分析：\n")
grad_norms_with = []
grad_norms_without = []
# 有残差
for i, layer in enumerate(model_with_res):
for param in layer.parameters():
if param.grad is not None:
grad_norms_with.append(param.grad.norm().item())
break
# 无残差
for i, layer in enumerate(model_without_res):
for param in layer.parameters():
if param.grad is not None:
grad_norms_without.append(param.grad.norm().item())
break
# 可视化
fig, ax = plt.subplots(figsize=(12, 6))
layers = range(1, n_layers + 1)
ax.plot(layers, grad_norms_with, marker='o', linewidth=2.5,
label='有残差连接', color='green')
ax.plot(layers, grad_norms_without, marker='s', linewidth=2.5,
label='无残差连接', color='red')
ax.set_xlabel('层编号', fontsize=12)
ax.set_ylabel('梯度范数', fontsize=12)
ax.set_title('梯度在网络中的传播', fontsize=14, fontweight='bold')
ax.legend(fontsize=11)
ax.grid(True, alpha=0.3)
ax.set_yscale('log')
plt.tight_layout()
plt.show()
print("观察：")
print(" ✓ 有残差：梯度相对稳定")
print(" ✓ 无残差：梯度逐层衰减（梯度消失）\n")
def explain_layer_normalization(self):
"""解释层归一化"""
print("\n实验19：层归一化 vs 批归一化\n")
print("Layer Normalization (LN)：")
print(" 对每个样本的特征维度归一化")
print(" μ = mean(x[i, :]) # 对特征维度求均值")
print(" σ = std(x[i, :]) # 对特征维度求标准差")
print(" LN(x[i]) = γ × (x[i] - μ) / σ + β\n")
print("Batch Normalization (BN)：")
print(" 对每个特征维度的批次归一化")
print(" μ = mean(x[:, j]) # 对批次维度求均值")
print(" σ = std(x[:, j]) # 对批次维度求标准差\n")
# 可视化对比
batch_size = 4
seq_len = 5
d_model = 6
x = torch.randn(batch_size, seq_len, d_model)
# Layer Norm
ln = nn.LayerNorm(d_model)
x_ln = ln(x)
# Batch Norm (需要调整维度)
bn = nn.BatchNorm1d(d_model)
x_bn = bn(x.transpose(1, 2)).transpose(1, 2)
fig, axes = plt.subplots(1, 3, figsize=(16, 4))
# 原始数据
im1 = axes[0].imshow(x[0].numpy(), cmap='coolwarm', aspect='auto')
axes[0].set_title('原始数据（第1个样本）', fontweight='bold')
axes[0].set_xlabel('特征维度')
axes[0].set_ylabel('序列位置')
plt.colorbar(im1, ax=axes[0])
# Layer Norm
im2 = axes[1].imshow(x_ln[0].detach().numpy(), cmap='coolwarm', aspect='auto')
axes[1].set_title('Layer Norm后', fontweight='bold')
axes[1].set_xlabel('特征维度')
axes[1].set_ylabel('序列位置')
plt.colorbar(im2, ax=axes[1])
# Batch Norm
im3 = axes[2].imshow(x_bn[0].detach().numpy(), cmap='coolwarm', aspect='auto')
axes[2].set_title('Batch Norm后', fontweight='bold')
axes[2].set_xlabel('特征维度')
axes[2].set_ylabel('序列位置')
plt.colorbar(im3, ax=axes[2])
plt.tight_layout()
plt.show()
print("为什么Transformer使用Layer Norm？")
print(" 1. 序列长度可变：BN依赖批次统计，处理变长序列困难")
print(" 2. 小批次友好：LN不依赖批次大小")
print(" 3. 推理一致性：LN训练和推理行为相同")
print(" 4. RNN友好：可以逐步处理序列\n")
res_analyzer = ResidualConnectionAnalyzer()
res_analyzer.explain_residual_connection()
res_analyzer.demonstrate_gradient_flow()
res_analyzer.explain_layer_normalization()
🤖 第七章：从GPT到BERT - 预训练范式的分野
7.1 自回归语言模型：GPT系列
class GPTStyleDecoder(nn.Module):
"""GPT风格的仅解码器架构"""
def __init__(
self,
vocab_size,
d_model=768,
n_heads=12,
n_layers=12,
d_ff=3072,
max_len=1024,
dropout=0.1
):
super().__init__()
# Token嵌入
self.token_embedding = nn.Embedding(vocab_size, d_model)
# 位置嵌入（可学习）
self.position_embedding = nn.Embedding(max_len, d_model)
# Transformer解码器层（仅使用掩码自注意力）
self.layers = nn.ModuleList([
GPTBlock(d_model, n_heads, d_ff, dropout)
for _ in range(n_layers)
])
# 输出层
self.ln_f = nn.LayerNorm(d_model)
self.head = nn.Linear(d_model, vocab_size, bias=False)
# 权重绑定（Token嵌入和输出层共享权重）
self.head.weight = self.token_embedding.weight
self.dropout = nn.Dropout(dropout)
def forward(self, input_ids, past_key_values=None):
"""
Args:
input_ids: [batch, seq_len]
past_key_values: 缓存的K, V（用于生成）
Returns:
logits: [batch, seq_len, vocab_size]
"""
batch_size, seq_len = input_ids.shape
# 位置索引
if past_key_values is None:
past_length = 0
position_ids = torch.arange(0, seq_len, device=input_ids.device)
else:
past_length = past_key_values[0][0].size(-2)
position_ids = torch.arange(past_length, past_length + seq_len,
device=input_ids.device)
position_ids = position_ids.unsqueeze(0)
# Token嵌入 + 位置嵌入
token_embeddings = self.token_embedding(input_ids)
position_embeddings = self.position_embedding(position_ids)
x = self.dropout(token_embeddings + position_embeddings)
# 通过所有层
presents = []
for i, layer in enumerate(self.layers):
past = past_key_values[i] if past_key_values is not None else None
x, present = layer(x, past=past)
presents.append(present)
x = self.ln_f(x)
# 输出logits
logits = self.head(x)
return logits, presents
class GPTBlock(nn.Module):
"""GPT块（仅掩码自注意力 + FFN）"""
def __init__(self, d_model, n_heads, d_ff, dropout):
super().__init__()
self.ln_1 = nn.LayerNorm(d_model)
self.attn = CausalSelfAttention(d_model, n_heads, dropout)
self.ln_2 = nn.LayerNorm(d_model)
self.mlp = nn.Sequential(
nn.Linear(d_model, d_ff),
nn.GELU(),
nn.Linear(d_ff, d_model),
nn.Dropout(dropout)
)
def forward(self, x, past=None):
# 掩码自注意力
attn_output, present = self.attn(self.ln_1(x), past=past)
x = x + attn_output
# FFN
x = x + self.mlp(self.ln_2(x))
return x, present
class CausalSelfAttention(nn.Module):
"""因果自注意力（GPT使用）"""
def __init__(self, d_model, n_heads, dropout):
super().__init__()
assert d_model % n_heads == 0
self.d_model = d_model
self.n_heads = n_heads
self.d_k = d_model // n_heads
# Q, K, V投影（合并为一个矩阵加速）
self.c_attn = nn.Linear(d_model, 3 * d_model)
# 输出投影
self.c_proj = nn.Linear(d_model, d_model)
self.attn_dropout = nn.Dropout(dropout)
self.resid_dropout = nn.Dropout(dropout)
# 因果掩码（下三角）
self.register_buffer(
"bias",
torch.tril(torch.ones(1024, 1024)).view(1, 1, 1024, 1024)
)
def forward(self, x, past=None):
batch_size, seq_len, d_model = x.shape
# 计算Q, K, V
qkv = self.c_attn(x)
q, k, v = qkv.split(self.d_model, dim=2)
# 重塑为多头
q = q.view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
k = k.view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
v = v.view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
# 如果有缓存，拼接
if past is not None:
past_k, past_v = past
k = torch.cat([past_k, k], dim=-2)
v = torch.cat([past_v, v], dim=-2)
present = (k, v)
# 注意力计算
attn = (q @ k.transpose(-2, -1)) / math.sqrt(self.d_k)
# 应用因果掩码
attn = attn.masked_fill(
self.bias[:, :, :seq_len, :k.size(-2)] == 0,
float('-inf')
)
attn = F.softmax(attn, dim=-1)
attn = self.attn_dropout(attn)
y = attn @ v
# 拼接多头
y = y.transpose(1, 2).contiguous().view(batch_size, seq_len, d_model)
# 输出投影
y = self.resid_dropout(self.c_proj(y))
return y, present
def demonstrate_gpt_generation():
"""演示GPT的文本生成"""
print("\n实验20：GPT自回归生成过程\n")
print("GPT的核心特点：")
print(" 1. 架构：仅解码器（Decoder-only）")
print(" 2. 训练：自回归语言建模")
print(" P(x₁, x₂, ..., xₙ) = ∏ P(xᵢ | x₁, ..., xᵢ₋₁)")
print(" 3. 掩码：因果掩码（只能看到左侧上下文）")
print(" 4. 任务：零样本/少样本学习\n")
# 创建小型GPT
vocab_size = 5000
gpt = GPTStyleDecoder(
vocab_size=vocab_size,
d_model=256,
n_heads=8,
n_layers=6,
d_ff=1024,
max_len=128
)
print(f"模型参数量: {sum(p.numel() for p in gpt.parameters()):,}\n")
# 模拟生成过程
print("生成过程模拟：")
print(" 输入提示: 'The cat sat on'")
print(" 目标: 生成接下来的词\n")
# 模拟输入（假设已tokenize）
input_ids = torch.tensor([[1, 234, 567, 89, 456]]) # [batch=1, seq_len=5]
# 前向传播
with torch.no_grad():
logits, _ = gpt(input_ids)
print(f"输出logits形状: {logits.shape}")
print(f" - [batch_size, seq_len, vocab_size]\n")
# 预测下一个词
next_token_logits = logits[0, -1, :] # 取最后一个位置
probs = F.softmax(next_token_logits, dim=-1)
# Top-5预测
top5_probs, top5_indices = torch.topk(probs, 5)
print("Top-5预测（假设词表）：")
fake_vocab = ['the', 'mat', 'floor', 'table', 'chair']
for i, (idx, prob) in enumerate(zip(top5_indices, top5_probs)):
print(f" {i+1}. '{fake_vocab[i]}' (ID: {idx.item()}, 概率: {prob.item():.4f})")
print("\n生成策略：")
print(" • Greedy: 选择概率最高的词")
print(" • Sampling: 按概率分布随机采样")
print(" • Top-k Sampling: 从概率最高的k个词中采样")
print(" • Nucleus (Top-p) Sampling: 从累积概率达到p的词中采样\n")
# 可视化因果掩码
seq_len = 10
causal_mask = torch.tril(torch.ones(seq_len, seq_len))
plt.figure(figsize=(8, 8))
plt.imshow(causal_mask.numpy(), cmap='Greys', interpolation='nearest')
plt.title('GPT的因果注意力掩码', fontsize=14, fontweight='bold')
plt.xlabel('Key位置（可见的上下文）', fontsize=12)
plt.ylabel('Query位置（当前生成位置）', fontsize=12)
# 标注
for i in range(seq_len):
for j in range(seq_len):
text = '✓' if causal_mask[i, j] == 1 else '✗'
color = 'white' if causal_mask[i, j] == 1 else 'black'
plt.text(j, i, text, ha='center', va='center',
color=color, fontsize=12, fontweight='bold')
plt.tight_layout()
plt.show()
print("掩码解读：")
print(" ✓ 白色区域：允许注意")
print(" ✗ 黑色区域：禁止注意（未来信息）")
print(" → 确保生成第i个词时，只能看到前i-1个词\n")
demonstrate_gpt_generation()
7.2 掩码语言模型：BERT
class BERTStyleEncoder(nn.Module):
"""BERT风格的仅编码器架构"""
def __init__(
self,
vocab_size,
d_model=768,
n_heads=12,
n_layers=12,
d_ff=3072,
max_len=512,
dropout=0.1
):
super().__init__()
# Token嵌入
self.token_embedding = nn.Embedding(vocab_size, d_model)
# 位置嵌入
self.position_embedding = nn.Embedding(max_len, d_model)
# Token类型嵌入（用于句子对任务）
self.token_type_embedding = nn.Embedding(2, d_model)
# Transformer编码器层
self.layers = nn.ModuleList([
EncoderLayer(d_model, n_heads, d_ff, dropout)
for _ in range(n_layers)
])
self.ln = nn.LayerNorm(d_model)
self.dropout = nn.Dropout(dropout)
def forward(self, input_ids, token_type_ids=None, attention_mask=None):
"""
Args:
input_ids: [batch, seq_len]
token_type_ids: [batch, seq_len] (0或1，区分句子A/B)
attention_mask: [batch, seq_len] (1=有效，0=padding)
Returns:
hidden_states: [batch, seq_len, d_model]
"""
batch_size, seq_len = input_ids.shape
# 位置索引
position_ids = torch.arange(0, seq_len, device=input_ids.device)
position_ids = position_ids.unsqueeze(0).expand_as(input_ids)
# Token类型（默认全0）
if token_type_ids is None:
token_type_ids = torch.zeros_like(input_ids)
# 三种嵌入相加
token_embeddings = self.token_embedding(input_ids)
position_embeddings = self.position_embedding(position_ids)
token_type_embeddings = self.token_type_embedding(token_type_ids)
embeddings = token_embeddings + position_embeddings + token_type_embeddings
embeddings = self.dropout(embeddings)
# 扩展attention_mask
if attention_mask is not None:
attention_mask = attention_mask.unsqueeze(1).unsqueeze(2)
# [batch, 1, 1, seq_len]
# 通过所有编码器层
hidden_states = embeddings
for layer in self.layers:
hidden_states, _ = layer(hidden_states, attention_mask)
hidden_states = self.ln(hidden_states)
return hidden_states
class MLMHead(nn.Module):
"""掩码语言模型头"""
def __init__(self, d_model, vocab_size):
super().__init__()
self.dense = nn.Linear(d_model, d_model)
self.layer_norm = nn.LayerNorm(d_model)
self.decoder = nn.Linear(d_model, vocab_size, bias=False)
self.bias = nn.Parameter(torch.zeros(vocab_size))
self.decoder.bias = self.bias
def forward(self, hidden_states):
"""
Args:
hidden_states: [batch, seq_len, d_model]
Returns:
logits: [batch, seq_len, vocab_size]
"""
hidden_states = self.dense(hidden_states)
hidden_states = F.gelu(hidden_states)
hidden_states = self.layer_norm(hidden_states)
logits = self.decoder(hidden_states)
return logits
def demonstrate_bert_mlm():
"""演示BERT的掩码语言建模"""
print("\n实验21：BERT掩码语言建模\n")
print("BERT的核心特点：")
print(" 1. 架构：仅编码器（Encoder-only）")
print(" 2. 训练：掩码语言建模（MLM）+ 下一句预测（NSP）")
print(" 3. 掩码：无掩码（双向注意力）")
print(" 4. 任务：特征提取、分类、问答等\n")
# 创建BERT
vocab_size = 30000
bert = BERTStyleEncoder(
vocab_size=vocab_size,
d_model=768,
n_heads=12,
n_layers=12,
d_ff=3072,
max_len=512
)
mlm_head = MLMHead(768, vocab_size)
print(f"BERT参数量: {sum(p.numel() for p in bert.parameters()):,}")
print(f"MLM头参数量: {sum(p.numel() for p in mlm_head.parameters()):,}\n")
# 模拟MLM任务
print("MLM训练示例：")
original_text = "The quick brown fox jumps over the lazy dog"
masked_text = "The quick [MASK] fox jumps over the [MASK] dog"
print(f" 原始: {original_text}")
print(f" 掩码: {masked_text}")
print(f" 目标: 预测 [MASK] 位置的词\n")
# 模拟输入（假设已tokenize）
# [CLS] The quick [MASK] fox ... [MASK] dog [SEP]
input_ids = torch.tensor([[
101, # [CLS]
1996, 4248, 103, 4419, 14523, 2058, 1996, 103, 3899,
102 # [SEP]
]])
# 掩码位置
masked_positions = [3, 9] # 索引
# 前向传播
with torch.no_grad():
hidden_states = bert(input_ids)
logits = mlm_head(hidden_states)
print(f"输出logits形状: {logits.shape}\n")
# 预测掩码位置
print("预测结果：")
fake_vocab = {103: '[MASK]', 2829: 'brown', 13971: 'lazy'}
for pos in masked_positions:
masked_logits = logits[0, pos, :]
probs = F.softmax(masked_logits, dim=-1)
# Top-3预测
top3_probs, top3_indices = torch.topk(probs, 3)
print(f"\n 位置{pos} ([MASK]):")
for i, (idx, prob) in enumerate(zip(top3_indices, top3_probs)):
word = fake_vocab.get(idx.item(), f'word_{idx.item()}')
print(f" {i+1}. {word} (概率: {prob.item():.4f})")
print("\n\nMLM训练策略（BERT论文）：")
print(" 1. 随机选择15%的token")
print(" 2. 其中：")
print(" - 80%替换为[MASK]")
print(" - 10%替换为随机词")
print(" - 10%保持不变")
print(" 3. 目的：防止模型过度依赖[MASK]标记\n")
# 可视化双向注意力
seq_len = 10
bidirectional_mask = torch.ones(seq_len, seq_len)
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 6))
# BERT双向注意力
im1 = ax1.imshow(bidirectional_mask.numpy(), cmap='Greens',
interpolation='nearest')
ax1.set_title('BERT双向注意力（无掩码）', fontsize=13, fontweight='bold')
ax1.set_xlabel('Key位置', fontsize=11)
ax1.set_ylabel('Query位置', fontsize=11)
plt.colorbar(im1, ax=ax1)
# GPT因果注意力（对比）
causal_mask = torch.tril(torch.ones(seq_len, seq_len))
im2 = ax2.imshow(causal_mask.numpy(), cmap='Reds',
interpolation='nearest')
ax2.set_title('GPT因果注意力（对比）', fontsize=13, fontweight='bold')
ax2.set_xlabel('Key位置', fontsize=11)
ax2.set_ylabel('Query位置', fontsize=11)
plt.colorbar(im2, ax=ax2)
plt.tight_layout()
plt.show()
print("BERT vs GPT架构对比：\n")
comparison = {
'特性': ['架构', '注意力', '训练目标', '典型任务', '推理方式'],
'BERT': [
'编码器',
'双向（看全文）',
'MLM + NSP',
'分类、NER、QA',
'并行（一次处理全文）'
],
'GPT': [
'解码器',
'单向（仅看左侧）',
'自回归LM',
'生成、对话',
'自回归（逐词生成）'
]
}
print(f"{'特性':<15} {'BERT':<25} {'GPT':<25}")
print("="*70)
for i, feature in enumerate(comparison['特性']):
print(f"{feature:<15} {comparison['BERT'][i]:<25} {comparison['GPT'][i]:<25}")
print("\n适用场景：")
print(" • BERT：理解任务（分类、抽取、匹配）")
print(" • GPT：生成任务（文本生成、对话、翻译）\n")
demonstrate_bert_mlm()
👁️ 第八章：Vision Transformer - 计算机视觉的新纪元
8.1 从CNN到Transformer
class PatchEmbedding(nn.Module):
"""图像patch嵌入"""
def __init__(self, img_size=224, patch_size=16, in_channels=3, embed_dim=768):
super().__init__()
self.img_size = img_size
self.patch_size = patch_size
self.n_patches = (img_size // patch_size) ** 2
# 使用卷积实现patch嵌入（等价于线性投影）
self.proj = nn.Conv2d(
in_channels,
embed_dim,
kernel_size=patch_size,
stride=patch_size
)
def forward(self, x):
"""
Args:
x: [batch, channels, height, width]
Returns:
patches: [batch, n_patches, embed_dim]
"""
# [batch, embed_dim, h/p, w/p]
x = self.proj(x)
# [batch, embed_dim, n_patches]
x = x.flatten(2)
# [batch, n_patches, embed_dim]
x = x.transpose(1, 2)
return x
class VisionTransformer(nn.Module):
"""Vision Transformer (ViT)"""
def __init__(
self,
img_size=224,
patch_size=16,
in_channels=3,
num_classes=1000,
embed_dim=768,
n_heads=12,
n_layers=12,
d_ff=3072,
dropout=0.1
):
super().__init__()
# Patch嵌入
self.patch_embed = PatchEmbedding(
img_size, patch_size, in_channels, embed_dim
)
n_patches = self.patch_embed.n_patches
# [CLS] token
self.cls_token = nn.Parameter(torch.zeros(1, 1, embed_dim))
# 位置嵌入（包含[CLS]）
self.pos_embed = nn.Parameter(torch.zeros(1, n_patches + 1, embed_dim))
# Transformer编码器
self.encoder_layers = nn.ModuleList([
EncoderLayer(embed_dim, n_heads, d_ff, dropout)
for _ in range(n_layers)
])
self.norm = nn.LayerNorm(embed_dim)
# 分类头
self.head = nn.Linear(embed_dim, num_classes)
self.dropout = nn.Dropout(dropout)
# 初始化
nn.init.trunc_normal_(self.pos_embed, std=0.02)
nn.init.trunc_normal_(self.cls_token, std=0.02)
def forward(self, x):
"""
Args:
x: [batch, channels, height, width]
Returns:
logits: [batch, num_classes]
"""
batch_size = x.shape[0]
# Patch嵌入
x = self.patch_embed(x) # [batch, n_patches, embed_dim]
# 添加[CLS] token
cls_tokens = self.cls_token.expand(batch_size, -1, -1)
x = torch.cat([cls_tokens, x], dim=1)
# 添加位置嵌入
x = x + self.pos_embed
x = self.dropout(x)
# 通过Transformer编码器
for layer in self.encoder_layers:
x, _ = layer(x)
x = self.norm(x)
# 使用[CLS] token进行分类
cls_output = x[:, 0]
logits = self.head(cls_output)
return logits
def demonstrate_vit():
"""演示Vision Transformer"""
print("\n实验22：Vision Transformer原理\n")
print("ViT核心思想：将图像视为序列")
print(" 1. 将图像分割成固定大小的patches")
print(" 2. 线性投影每个patch到嵌入空间")
print(" 3. 添加位置嵌入")
print(" 4. 通过标准Transformer编码器")
print(" 5. 使用[CLS] token进行分类\n")
# 创建ViT
model = VisionTransformer(
img_size=224,
patch_size=16,
in_channels=3,
num_classes=1000,
embed_dim=768,
n_heads=12,
n_layers=12,
d_ff=3072
)
print(f"模型参数量: {sum(p.numel() for p in model.parameters()):,}\n")
# 模拟输入
batch_size = 4
img = torch.randn(batch_size, 3, 224, 224)
print(f"输入图像: {img.shape}")
print(f" - [batch_size, channels, height, width]\n")
# 前向传播
with torch.no_grad():
# Patch嵌入
patches = model.patch_embed(img)
print(f"Patch嵌入: {patches.shape}")
n_patches = model.patch_embed.n_patches
patch_size = model.patch_embed.patch_size
patches_per_side = int(n_patches ** 0.5)
print(f" - Patch大小: {patch_size}×{patch_size}")
print(f" - 每边Patch数: {patches_per_side}")
print(f" - 总Patch数: {n_patches}")
print(f" - 嵌入维度: {patches.shape[-1]}\n")
# 完整前向
logits = model(img)
print(f"输出logits: {logits.shape}")
print(f" - [batch_size, num_classes]\n")
# 可视化patch分割
fig, axes = plt.subplots(1, 3, figsize=(15, 5))
# 原始图像（模拟）
sample_img = torch.randn(3, 224, 224)
sample_img = (sample_img - sample_img.min()) / (sample_img.max() - sample_img.min())
axes[0].imshow(sample_img.permute(1, 2, 0).numpy())
axes[0].set_title('原始图像 (224×224)', fontsize=13, fontweight='bold')
axes[0].axis('off')
# Patch网格
axes[1].imshow(sample_img.permute(1, 2, 0).numpy())
# 绘制网格线
for i in range(0, 224, patch_size):
axes[1].axhline(y=i, color='red', linewidth=2)
axes[1].axvline(x=i, color='red', linewidth=2)
axes[1].set_title(f'Patch分割 ({patches_per_side}×{patches_per_side})',
fontsize=13, fontweight='bold')
axes[1].axis('off')
# Patch序列可视化
with torch.no_grad():
single_patch_embed = model.patch_embed(sample_img.unsqueeze(0))
patch_matrix = single_patch_embed[0].numpy() # [196, 768]
axes[2].imshow(patch_matrix.T, aspect='auto', cmap='viridis')
axes[2].set_title(f'Patch嵌入矩阵 ({n_patches}×{patches.shape[-1]})',
fontsize=13, fontweight='bold')
axes[2].set_xlabel('Patch索引')
axes[2].set_ylabel('嵌入维度')
plt.tight_layout()
plt.show()
print("ViT vs CNN对比：\n")
comparison = {
'特性': ['归纳偏置', '参数共享', '局部性', '全局建模', '数据需求', '可解释性'],
'CNN': [
'强（卷积+池化）',
'高（卷积核共享）',
'天然（感受野）',
'需要深层堆叠',
'相对较少',
'较好（可视化滤波器）'
],
'ViT': [
'弱（仅位置编码）',
'低（每层独立参数）',
'需要学习',
'天然（自注意力）',
'大量（ImageNet-21K）',
'一般（注意力图）'
]
}
print(f"{'特性':<15} {'CNN':<30} {'ViT':<30}")
print("="*80)
for i, feature in enumerate(comparison['特性']):
print(f"{feature:<15} {comparison['CNN'][i]:<30} {comparison['ViT'][i]:<30}")
print("\n关键发现（ViT论文）：")
print(" ✓ 小数据集：CNN表现更好（归纳偏置有利）")
print(" ✓ 大数据集：ViT超越CNN（学习更通用的特征）")
print(" ✓ 混合架构：早期卷积 + 后期Transformer效果最佳\n")
demonstrate_vit()
8.2 注意力图可视化
def visualize_vit_attention():
"""可视化ViT的注意力图"""
print("\n实验23：ViT注意力图可视化\n")
# 创建简化的ViT
model = VisionTransformer(
img_size=224,
patch_size=16,
in_channels=3,
num_classes=10, # 简化
embed_dim=256,
n_heads=8,
n_layers=6
)
model.eval()
# 模拟输入（单张图片）
img = torch.randn(1, 3, 224, 224)
# 修改模型以返回注意力权重
attentions = []
def hook_fn(module, input, output):
# output[1] 是注意力权重
attentions.append(output[1].detach())
# 注册hook
hooks = []
for layer in model.encoder_layers:
hook = layer.self_attention.register_forward_hook(hook_fn)
hooks.append(hook)
# 前向传播
with torch.no_grad():
_ = model(img)
# 移除hook
for hook in hooks:
hook.remove()
# 可视化不同层的注意力
n_layers = len(attentions)
fig, axes = plt.subplots(2, 3, figsize=(15, 10))
axes = axes.flatten()
n_patches = model.patch_embed.n_patches
patches_per_side = int(n_patches ** 0.5)
for layer_idx in range(min(6, n_layers)):
ax = axes[layer_idx]
# 获取该层的注意力 [1, n_heads, seq_len, seq_len]
attn = attentions[layer_idx][0] # [n_heads, seq_len, seq_len]
# 平均所有头
attn_avg = attn.mean(dim=0) # [seq_len, seq_len]
# 关注[CLS] token对patches的注意力
cls_attn = attn_avg[0, 1:] # 去掉[CLS]自身
# Reshape到2D
cls_attn_2d = cls_attn.reshape(patches_per_side, patches_per_side)
im = ax.imshow(cls_attn_2d.numpy(), cmap='hot', interpolation='nearest')
ax.set_title(f'Layer {layer_idx + 1}', fontsize=12, fontweight='bold')
ax.axis('off')
plt.colorbar(im, ax=ax, fraction=0.046, pad=0.04)
plt.suptitle('[CLS] Token的注意力分布（不同层）',
fontsize=14, fontweight='bold')
plt.tight_layout()
plt.show()
print("观察：")
print(" • 早期层：注意力分散（学习局部特征）")
print(" • 中间层：注意力聚焦到特定区域")
print(" • 后期层：注意力高度集中（语义相关区域）\n")
# 分析注意力距离
print("注意力距离分析：\n")
for layer_idx in range(n_layers):
attn = attentions[layer_idx][0] # [n_heads, seq_len, seq_len]
# 计算平均注意力距离
distances = []
for head in range(attn.shape[0]):
head_attn = attn[head, 1:, 1:] # 去掉[CLS]
# 计算每个patch关注的平均位置
for i in range(n_patches):
weights = head_attn[i]
# 计算加权平均距离
i_row, i_col = i // patches_per_side, i % patches_per_side
total_distance = 0
for j, w in enumerate(weights):
j_row, j_col = j // patches_per_side, j % patches_per_side
dist = abs(i_row - j_row) + abs(i_col - j_col) # Manhattan距离
total_distance += w.item() * dist
distances.append(total_distance)
avg_distance = np.mean(distances)
print(f" Layer {layer_idx + 1}: 平均注意力距离 = {avg_distance:.2f} patches")
print("\n结论：")
print(" ✓ 深层网络学习更全局的特征（注意力距离增大）")
print(" ✓ 不同头关注不同尺度的特征\n")
visualize_vit_attention()
继续第九章...
⚡ 第九章：高效Transformer - 稀疏注意力与线性复杂度
9.1 标准注意力的瓶颈
def analyze_attention_complexity():
"""分析标准注意力的复杂度瓶颈"""
print("\n实验24：标准注意力的计算与内存瓶颈\n")
print("标准自注意力：")
print(" Attention(Q, K, V) = softmax(QK^T / √d_k) V\n")
print("复杂度分析：")
print(" • 时间复杂度: O(n² · d)")
print(" - QK^T: O(n² · d)")
print(" - softmax(...)V: O(n² · d)")
print(" • 空间复杂度: O(n²)")
print(" - 注意力矩阵: [n, n]\n")
print("问题：序列长度n增长时，成本呈平方增长！\n")
# 可视化不同序列长度的成本
seq_lengths = [512, 1024, 2048, 4096, 8192, 16384]
d_model = 512
time_costs = []
memory_costs = []
for n in seq_lengths:
# 时间（FLOPs）
time = 2 * n**2 * d_model / 1e9 # GFLOPs
time_costs.append(time)
# 内存（注意力矩阵）
memory = n**2 * 4 / 1024**2 # MB (float32)
memory_costs.append(memory)
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 5))
# 计算成本
ax1.plot(seq_lengths, time_costs, marker='o', linewidth=2.5,
color='red', markersize=8)
ax1.set_xlabel('序列长度', fontsize=12)
ax1.set_ylabel('计算量 (GFLOPs)', fontsize=12)
ax1.set_title('计算成本随序列长度变化', fontsize=14, fontweight='bold')
ax1.grid(True, alpha=0.3)
ax1.set_xscale('log', base=2)
ax1.set_yscale('log')
# 标注关键点
for x, y in zip(seq_lengths[::2], time_costs[::2]):
ax1.annotate(f'{y:.1f}', xy=(x, y), xytext=(10, 10),
textcoords='offset points', fontsize=10,
bbox=dict(boxstyle='round', facecolor='yellow', alpha=0.5))
# 内存成本
ax2.plot(seq_lengths, memory_costs, marker='s', linewidth=2.5,
color='blue', markersize=8)
ax2.set_xlabel('序列长度', fontsize=12)
ax2.set_ylabel('内存占用 (MB)', fontsize=12)
ax2.set_title('内存占用随序列长度变化', fontsize=14, fontweight='bold')
ax2.grid(True, alpha=0.3)
ax2.set_xscale('log', base=2)
ax2.set_yscale('log')
# 标注GPU内存限制
ax2.axhline(y=16*1024, color='red', linestyle='--', linewidth=2,
label='GPU内存限制 (16GB)')
ax2.legend(fontsize=11)
for x, y in zip(seq_lengths[::2], memory_costs[::2]):
ax2.annotate(f'{y:.0f}', xy=(x, y), xytext=(10, 10),
textcoords='offset points', fontsize=10,
bbox=dict(boxstyle='round', facecolor='lightblue', alpha=0.5))
plt.tight_layout()
plt.show()
print("实际限制：")
print(f" • seq_len=2048: 内存 {memory_costs[2]:.0f} MB")
print(f" • seq_len=8192: 内存 {memory_costs[4]:.0f} MB")
print(f" • seq_len=16384: 内存 {memory_costs[5]:.0f} MB (超出单GPU容量！)\n")
print("应用场景需求：")
print(" • 长文档理解: 10k+ tokens")
print(" • 蛋白质序列: 数千残基")
print(" • 高分辨率图像: 数万patches")
print(" • 长视频: 数万帧\n")
print("解决方案：")
print(" 1. 稀疏注意力")
print(" 2. 线性注意力")
print(" 3. 分块/滑动窗口注意力")
print(" 4. Flash Attention (硬件优化)\n")
analyze_attention_complexity()
9.2 稀疏注意力机制
class SparseAttentionPatterns:
"""稀疏注意力模式"""
def __init__(self):
pass
def local_attention(self, seq_len, window_size):
"""局部注意力（滑动窗口）"""
mask = torch.zeros(seq_len, seq_len)
for i in range(seq_len):
start = max(0, i - window_size // 2)
end = min(seq_len, i + window_size // 2 + 1)
mask[i, start:end] = 1
return mask
def strided_attention(self, seq_len, stride):
"""步幅注意力"""
mask = torch.zeros(seq_len, seq_len)
for i in range(seq_len):
# 每隔stride个位置
indices = list(range(0, seq_len, stride))
if i not in indices:
indices.append(i)
mask[i, indices] = 1
return mask
def block_sparse_attention(self, seq_len, block_size):
"""块稀疏注意力"""
n_blocks = seq_len // block_size
mask = torch.zeros(seq_len, seq_len)
for i in range(n_blocks):
for j in range(n_blocks):
# 对角块和相邻块
if abs(i - j) <= 1:
start_i = i * block_size
end_i = (i + 1) * block_size
start_j = j * block_size
end_j = (j + 1) * block_size
mask[start_i:end_i, start_j:end_j] = 1
return mask
def visualize_patterns(self):
"""可视化不同稀疏模式"""
print("\n实验25：稀疏注意力模式\n")
seq_len = 64
# 生成不同模式
full_mask = torch.ones(seq_len, seq_len)
local_mask = self.local_attention(seq_len, window_size=8)
strided_mask = self.strided_attention(seq_len, stride=4)
block_mask = self.block_sparse_attention(seq_len, block_size=8)
# 计算稀疏度
def sparsity(mask):
return (1 - mask.sum() / mask.numel()) * 100
fig, axes = plt.subplots(2, 2, figsize=(12, 12))
patterns = [
('全注意力 (标准)', full_mask),
('局部注意力 (窗口=8)', local_mask),
('步幅注意力 (步长=4)', strided_mask),
('块稀疏注意力 (块=8)', block_mask)
]
for ax, (title, mask) in zip(axes.flatten(), patterns):
im = ax.imshow(mask.numpy(), cmap='Greys', interpolation='nearest')
ax.set_title(f'{title}\n稀疏度: {sparsity(mask):.1f}%',
fontsize=12, fontweight='bold')
ax.set_xlabel('Key位置')
ax.set_ylabel('Query位置')
plt.colorbar(im, ax=ax)
plt.tight_layout()
plt.show()
# 复杂度分析
print("复杂度对比：\n")
print(f"{'模式':<20} {'时间复杂度':<20} {'空间复杂度':<20} {'稀疏度':<15}")
print("="*80)
complexities = [
('全注意力', 'O(n²·d)', 'O(n²)', f'{sparsity(full_mask):.1f}%'),
('局部注意力', 'O(n·w·d)', 'O(n·w)', f'{sparsity(local_mask):.1f}%'),
('步幅注意力', 'O(n·n/s·d)', 'O(n·n/s)', f'{sparsity(strided_mask):.1f}%'),
('块稀疏', 'O(n·b·d)', 'O(n·b)', f'{sparsity(block_mask):.1f}%')
]
for name, time, space, sparse in complexities:
print(f"{name:<20} {time:<20} {space:<20} {sparse:<15}")
print("\n图例：")
print(" n: 序列长度")
print(" d: 特征维度")
print(" w: 窗口大小")
print(" s: 步幅")
print(" b: 块大小\n")
class LongformerAttention(nn.Module):
"""Longformer的注意力机制（局部+全局）"""
def __init__(self, d_model, n_heads, window_size, n_global_tokens=1):
super().__init__()
self.d_model = d_model
self.n_heads = n_heads
self.d_k = d_model // n_heads
self.window_size = window_size
self.n_global_tokens = n_global_tokens
self.W_q = nn.Linear(d_model, d_model)
self.W_k = nn.Linear(d_model, d_model)
self.W_v = nn.Linear(d_model, d_model)
self.W_o = nn.Linear(d_model, d_model)
def forward(self, x):
"""
Args:
x: [batch, seq_len, d_model]
Returns:
output: [batch, seq_len, d_model]
"""
batch_size, seq_len, _ = x.shape
# Q, K, V投影
Q = self.W_q(x).view(batch_size, seq_len, self.n_heads, self.d_k)
K = self.W_k(x).view(batch_size, seq_len, self.n_heads, self.d_k)
V = self.W_v(x).view(batch_size, seq_len, self.n_heads, self.d_k)
Q = Q.transpose(1, 2) # [batch, n_heads, seq_len, d_k]
K = K.transpose(1, 2)
V = V.transpose(1, 2)
# 简化实现：仅演示局部窗口
# 实际Longformer使用更高效的滑动窗口实现
output = torch.zeros_like(Q)
for i in range(seq_len):
# 局部窗口
start = max(0, i - self.window_size // 2)
end = min(seq_len, i + self.window_size // 2 + 1)
# 全局tokens（如[CLS]）
if i < self.n_global_tokens:
# 全局token关注所有位置
k_window = K
v_window = V
else:
k_window = K[:, :, start:end, :]
v_window = V[:, :, start:end, :]
q_i = Q[:, :, i:i+1, :]
# 注意力计算
scores = torch.matmul(q_i, k_window.transpose(-2, -1)) / math.sqrt(self.d_k)
attn = F.softmax(scores, dim=-1)
output[:, :, i:i+1, :] = torch.matmul(attn, v_window)
output = output.transpose(1, 2).contiguous()
output = output.view(batch_size, seq_len, self.d_model)
output = self.W_o(output)
return output
sparse_patterns = SparseAttentionPatterns()
sparse_patterns.visualize_patterns()
9.3 线性注意力
class LinearAttention(nn.Module):
"""线性注意力（Performer风格）"""
def __init__(self, d_model, n_heads, n_features=256):
super().__init__()
self.d_model = d_model
self.n_heads = n_heads
self.d_k = d_model // n_heads
self.n_features = n_features
self.W_q = nn.Linear(d_model, d_model)
self.W_k = nn.Linear(d_model, d_model)
self.W_v = nn.Linear(d_model, d_model)
self.W_o = nn.Linear(d_model, d_model)
def kernel_feature_map(self, x):
"""特征映射函数（简化的随机特征）"""
# φ(x) = exp(x²/2) / √d_k
# 实际Performer使用更复杂的正交随机特征
return F.elu(x) + 1 # 简化版本，确保非负
def forward(self, x):
"""
线性注意力核心思想：
Attention(Q, K, V) = φ(Q) · (φ(K)^T · V) / (φ(Q) · φ(K)^T · 1)
复杂度：O(n · d²) 而非 O(n² · d)
"""
batch_size, seq_len, _ = x.shape
Q = self.W_q(x).view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
K = self.W_k(x).view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
V = self.W_v(x).view(batch_size, seq_len, self.n_heads, self.d_k).transpose(1, 2)
# 应用特征映射
Q_prime = self.kernel_feature_map(Q) # [batch, n_heads, seq_len, d_k]
K_prime = self.kernel_feature_map(K)
# 关键：改变计算顺序
# 标准: (Q @ K^T) @ V -> O(n²d)
# 线性: Q @ (K^T @ V) -> O(nd²)
# K^T @ V: [batch, n_heads, d_k, d_k]
KV = torch.matmul(K_prime.transpose(-2, -1), V)
# Q @ KV: [batch, n_heads, seq_len, d_k]
QKV = torch.matmul(Q_prime, KV)
# 归一化
K_sum = K_prime.sum(dim=-2, keepdim=True).transpose(-2, -1) # [batch, n_heads, d_k, 1]
normalizer = torch.matmul(Q_prime, K_sum) # [batch, n_heads, seq_len, 1]
output = QKV / (normalizer + 1e-6)
output = output.transpose(1, 2).contiguous().view(batch_size, seq_len, self.d_model)
output = self.W_o(output)
return output
def compare_attention_mechanisms():
"""对比不同注意力机制"""
print("\n实验26：高效注意力机制对比\n")
d_model = 512
n_heads = 8
batch_size = 4
# 测试不同序列长度
seq_lengths = [128, 256, 512, 1024, 2048, 4096]
# 创建模型
standard_attn = MultiHeadAttention(d_model, n_heads)
linear_attn = LinearAttention(d_model, n_heads)
longformer_attn = LongformerAttention(d_model, n_heads, window_size=256)
import time
standard_times = []
linear_times = []
longformer_times = []
print("性能测试进行中...\n")
for seq_len in seq_lengths:
x = torch.randn(batch_size, seq_len, d_model)
# 标准注意力
start = time.time()
with torch.no_grad():
for _ in range(10):
_ = standard_attn(x, x, x)
standard_time = (time.time() - start) / 10
standard_times.append(standard_time * 1000)
# 线性注意力
start = time.time()
with torch.no_grad():
for _ in range(10):
_ = linear_attn(x)
linear_time = (time.time() - start) / 10
linear_times.append(linear_time * 1000)
# Longformer（仅在seq_len不太长时测试）
if seq_len <= 1024:
start = time.time()
with torch.no_grad():
for _ in range(10):
_ = longformer_attn(x)
longformer_time = (time.time() - start) / 10
longformer_times.append(longformer_time * 1000)
else:
longformer_times.append(None)
# 可视化
fig, ax = plt.subplots(figsize=(12, 6))
ax.plot(seq_lengths, standard_times, marker='o', linewidth=2.5,
label='标准注意力 O(n²d)', color='red', markersize=8)
ax.plot(seq_lengths, linear_times, marker='s', linewidth=2.5,
label='线性注意力 O(nd²)', color='blue', markersize=8)
# Longformer（部分数据）
valid_longformer = [(sl, t) for sl, t in zip(seq_lengths, longformer_times) if t is not None]
if valid_longformer:
sl_long, t_long = zip(*valid_longformer)
ax.plot(sl_long, t_long, marker='^', linewidth=2.5,
label='Longformer O(nwd)', color='green', markersize=8)
ax.set_xlabel('序列长度', fontsize=12)
ax.set_ylabel('推理时间 (ms)', fontsize=12)
ax.set_title('不同注意力机制的性能对比', fontsize=14, fontweight='bold')
ax.legend(fontsize=11)
ax.grid(True, alpha=0.3)
ax.set_xscale('log', base=2)
ax.set_yscale('log')
plt.tight_layout()
plt.show()
# 打印详细结果
print("详细性能数据：\n")
print(f"{'序列长度':<12} {'标准注意力':<15} {'线性注意力':<15} {'Longformer':<15}")
print("="*60)
for i, sl in enumerate(seq_lengths):
longformer_str = f"{longformer_times[i]:.2f} ms" if longformer_times[i] else "N/A"
print(f"{sl:<12} {standard_times[i]:<15.2f} {linear_times[i]:<15.2f} {longformer_str:<15}")
print("\n优势分析：")
print(" • 标准注意力：seq_len < 512时最快（高度优化）")
print(" • 线性注意力：seq_len > 2048时显著更快")
print(" • Longformer：平衡性能与准确性\n")
# 内存对比
print("内存占用对比（seq_len=4096）：\n")
seq_len = 4096
standard_mem = batch_size * n_heads * seq_len * seq_len * 4 / 1024**2
linear_mem = batch_size * n_heads * d_model // n_heads * d_model // n_heads * 4 / 1024**2
longformer_mem = batch_size * n_heads * seq_len * 256 * 4 / 1024**2
print(f" 标准注意力: {standard_mem:.2f} MB")
print(f" 线性注意力: {linear_mem:.2f} MB")
print(f" Longformer: {longformer_mem:.2f} MB")
print(f"\n 节省内存: {(1 - linear_mem/standard_mem)*100:.1f}% (线性)")
print(f" {(1 - longformer_mem/standard_mem)*100:.1f}% (Longformer)\n")
compare_attention_mechanisms()
🎨 第十章：Transformer在多模态中的应用
10.1 CLIP：连接视觉与语言
class CLIPModel(nn.Module):
"""CLIP: Contrastive Language-Image Pre-training"""
def __init__(
self,
# 图像编码器参数
img_size=224,
patch_size=16,
img_embed_dim=768,
img_n_layers=12,
img_n_heads=12,
# 文本编码器参数
vocab_size=49408,
text_embed_dim=512,
text_n_layers=12,
text_n_heads=8,
max_text_len=77,
# 共同参数
projection_dim=512
):
super().__init__()
# 图像编码器（ViT）
self.image_encoder = VisionTransformer(
img_size=img_size,
patch_size=patch_size,
in_channels=3,
num_classes=projection_dim, # 投影维度
embed_dim=img_embed_dim,
n_heads=img_n_heads,
n_layers=img_n_layers
)
# 文本编码器（Transformer）
self.text_encoder = BERTStyleEncoder(
vocab_size=vocab_size,
d_model=text_embed_dim,
n_heads=text_n_heads,
n_layers=text_n_layers,
max_len=max_text_len
)
# 投影层
self.text_projection = nn.Linear(text_embed_dim, projection_dim)
# 可学习的温度参数
self.logit_scale = nn.Parameter(torch.ones([]) * np.log(1 / 0.07))
def encode_image(self, images):
"""
Args:
images: [batch, 3, H, W]
Returns:
image_features: [batch, projection_dim]
"""
image_features = self.image_encoder(images)
# L2归一化
image_features = F.normalize(image_features, p=2, dim=-1)
return image_features
def encode_text(self, text_tokens):
"""
Args:
text_tokens: [batch, max_len]
Returns:
text_features: [batch, projection_dim]
"""
# 通过文本编码器
hidden_states = self.text_encoder(text_tokens)
# 使用[CLS] token
text_features = hidden_states[:, 0, :]
# 投影
text_features = self.text_projection(text_features)
# L2归一化
text_features = F.normalize(text_features, p=2, dim=-1)
return text_features
def forward(self, images, text_tokens):
"""
对比学习前向传播
Args:
images: [batch, 3, H, W]
text_tokens: [batch, max_len]
Returns:
logits_per_image: [batch, batch]
logits_per_text: [batch, batch]
"""
# 编码
image_features = self.encode_image(images)
text_features = self.encode_text(text_tokens)
# 计算相似度矩阵
# [batch, batch]
logit_scale = self.logit_scale.exp()
logits_per_image = logit_scale * image_features @ text_features.t()
logits_per_text = logits_per_image.t()
return logits_per_image, logits_per_text
def demonstrate_clip():
"""演示CLIP的工作原理"""
print("\n实验27：CLIP多模态学习\n")
print("CLIP核心思想：")
print(" 通过对比学习连接图像和文本")
print(" 正样本：匹配的图像-文本对")
print(" 负样本：不匹配的图像-文本对\n")
# 创建CLIP模型
clip = CLIPModel(
img_embed_dim=512,
img_n_layers=6,
text_embed_dim=512,
text_n_layers=6,
projection_dim=256
)
print(f"图像编码器参数: {sum(p.numel() for p in clip.image_encoder.parameters()):,}")
print(f"文本编码器参数: {sum(p.numel() for p in clip.text_encoder.parameters()):,}")
print(f"总参数量: {sum(p.numel() for p in clip.parameters()):,}\n")
# 模拟批次
batch_size = 4
images = torch.randn(batch_size, 3, 224, 224)
text_tokens = torch.randint(0, 49408, (batch_size, 77))
# 前向传播
with torch.no_grad():
logits_per_image, logits_per_text = clip(images, text_tokens)
print(f"图像-文本相似度矩阵: {logits_per_image.shape}\n")
# 可视化相似度矩阵
similarities = logits_per_image.detach().numpy()
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 6))
# 相似度热图
im1 = ax1.imshow(similarities, cmap='RdYlGn', aspect='auto')
ax1.set_title('图像-文本相似度矩阵', fontsize=13, fontweight='bold')
ax1.set_xlabel('文本索引', fontsize=11)
ax1.set_ylabel('图像索引', fontsize=11)
ax1.set_xticks(range(batch_size))
ax1.set_yticks(range(batch_size))
# 标注数值
for i in range(batch_size):
for j in range(batch_size):
text = f'{similarities[i, j]:.2f}'
color = 'white' if abs(similarities[i, j]) < 5 else 'black'
ax1.text(j, i, text, ha='center', va='center',
color=color, fontsize=10, fontweight='bold')
plt.colorbar(im1, ax=ax1)
# Softmax后的概率
probs = F.softmax(torch.tensor(similarities), dim=1).numpy()
im2 = ax2.imshow(probs, cmap='Blues', aspect='auto')
ax2.set_title('图像→文本匹配概率', fontsize=13, fontweight='bold')
ax2.set_xlabel('文本索引', fontsize=11)
ax2.set_ylabel('图像索引', fontsize=11)
ax2.set_xticks(range(batch_size))
ax2.set_yticks(range(batch_size))
for i in range(batch_size):
for j in range(batch_size):
text = f'{probs[i, j]:.2f}'
color = 'white' if probs[i, j] < 0.5 else 'black'
ax2.text(j, i, text, ha='center', va='center',
color=color, fontsize=10, fontweight='bold')
plt.colorbar(im2, ax=ax2)
plt.tight_layout()
plt.show()
print("对比损失（InfoNCE）：")
print(" L = -log( exp(sim(i,i)/τ) / Σⱼ exp(sim(i,j)/τ) )")
print(" 其中：")
print(" i: 正样本对")
print(" j: 所有样本")
print(" τ: 温度参数\n")
# 计算损失
labels = torch.arange(batch_size)
loss_img = F.cross_entropy(logits_per_image, labels)
loss_txt = F.cross_entropy(logits_per_text, labels)
total_loss = (loss_img + loss_txt) / 2
print(f"图像→文本损失: {loss_img.item():.4f}")
print(f"文本→图像损失: {loss_txt.item():.4f}")
print(f"总损失: {total_loss.item():.4f}\n")
print("CLIP的应用：")
print(" 1. 零样本图像分类")
print(" - 将类别名转换为文本嵌入")
print(" - 计算图像与所有类别的相似度")
print(" 2. 图像检索")
print(" - 文本查询 → 检索相似图像")
print(" 3. 视觉问答")
print(" 4. 图像生成引导（DALL-E 2）\n")
demonstrate_clip()
10.2 多模态Transformer：Flamingo
class CrossAttentionLayer(nn.Module):
"""交叉注意力层（视觉→语言）"""
def __init__(self, d_model, n_heads, dropout=0.1):
super().__init__()
self.cross_attention = MultiHeadAttention(d_model, n_heads, dropout)
self.norm = nn.LayerNorm(d_model)
self.dropout = nn.Dropout(dropout)
def forward(self, text_hidden, vision_hidden, mask=None):
"""
Args:
text_hidden: [batch, text_len, d_model] (Query)
vision_hidden: [batch, vision_len, d_model] (Key, Value)
mask: 注意力掩码
Returns:
output: [batch, text_len, d_model]
"""
# 交叉注意力：文本关注视觉特征
attn_output, attn_weights = self.cross_attention(
text_hidden, # Q from text
vision_hidden, # K from vision
vision_hidden, # V from vision
mask
)
# 残差连接 + 层归一化
output = self.norm(text_hidden + self.dropout(attn_output))
return output, attn_weights
class MultimodalTransformerBlock(nn.Module):
"""多模态Transformer块"""
def __init__(self, d_model, n_heads, d_ff, dropout=0.1):
super().__init__()
# 自注意力（文本）
self.self_attention = MultiHeadAttention(d_model, n_heads, dropout)
self.norm1 = nn.LayerNorm(d_model)
# 交叉注意力（视觉→文本）
self.cross_attention_layer = CrossAttentionLayer(d_model, n_heads, dropout)
# FFN
self.ffn = PositionwiseFeedForward(d_model, d_ff, dropout)
self.norm2 = nn.LayerNorm(d_model)
self.dropout = nn.Dropout(dropout)
def forward(self, text_hidden, vision_hidden, self_attn_mask=None, cross_attn_mask=None):
"""
Args:
text_hidden: [batch, text_len, d_model]
vision_hidden: [batch, vision_len, d_model]
Returns:
output: [batch, text_len, d_model]
"""
# 1. 自注意力（文本内部）
self_attn_out, _ = self.self_attention(text_hidden, text_hidden, text_hidden, self_attn_mask)
text_hidden = self.norm1(text_hidden + self.dropout(self_attn_out))
# 2. 交叉注意力（视觉→文本）
cross_attn_out, _ = self.cross_attention_layer(text_hidden, vision_hidden, cross_attn_mask)
# 3. FFN
ffn_out = self.ffn(cross_attn_out)
output = self.norm2(cross_attn_out + self.dropout(ffn_out))
return output
def demonstrate_multimodal_transformer():
"""演示多模态Transformer"""
print("\n实验28：多模态Transformer架构\n")
print("Flamingo架构特点：")
print(" 1. 冻结的视觉编码器（预训练ViT）")
print(" 2. 冻结的语言模型（预训练GPT）")
print(" 3. 交叉注意力层（连接视觉和语言）")
print(" 4. 仅训练交叉注意力参数\n")
# 参数
d_model = 512
n_heads = 8
batch_size = 2
text_len = 20
vision_len = 196 # 14×14 patches
# 创建模块
multimodal_block = MultimodalTransformerBlock(
d_model=d_model,
n_heads=n_heads,
d_ff=2048
)
# 模拟输入
text_hidden = torch.randn(batch_size, text_len, d_model)
vision_hidden = torch.randn(batch_size, vision_len, d_model)
# 前向传播
with torch.no_grad():
output = multimodal_block(text_hidden, vision_hidden)
print(f"文本输入: {text_hidden.shape}")
print(f"视觉输入: {vision_hidden.shape}")
print(f"输出: {output.shape}\n")
# 可视化交叉注意力
cross_attn_layer = CrossAttentionLayer(d_model, n_heads)
with torch.no_grad():
_, cross_attn_weights = cross_attn_layer(text_hidden, vision_hidden)
# 平均所有头
avg_cross_attn = cross_attn_weights[0].mean(dim=0).numpy() # [text_len, vision_len]
# Reshape视觉维度到2D
patches_per_side = int(vision_len ** 0.5)
fig, axes = plt.subplots(2, 3, figsize=(15, 10))
axes = axes.flatten()
# 选择几个文本位置
text_positions = [0, 5, 10, 15, 19]
text_labels = ['[IMG]', 'What', 'is', 'in', '?']
for i, (pos, label) in enumerate(zip(text_positions, text_labels)):
ax = axes[i]
# 该文本位置对所有视觉patch的注意力
attn_to_vision = avg_cross_attn[pos].reshape(patches_per_side, patches_per_side)
im = ax.imshow(attn_to_vision, cmap='hot', interpolation='nearest')
ax.set_title(f'文本位置 {pos}: "{label}"', fontsize=12, fontweight='bold')
ax.axis('off')
plt.colorbar(im, ax=ax, fraction=0.046, pad=0.04)
# 最后一个子图：平均注意力
avg_attn_all = avg_cross_attn.mean(axis=0).reshape(patches_per_side, patches_per_side)
im = axes[5].imshow(avg_attn_all, cmap='hot', interpolation='nearest')
axes[5].set_title('平均注意力分布', fontsize=12, fontweight='bold')
axes[5].axis('off')
plt.colorbar(im, ax=axes[5], fraction=0.046, pad=0.04)
plt.suptitle('交叉注意力：文本如何关注图像', fontsize=14, fontweight='bold')
plt.tight_layout()
plt.show()
print("观察：")
print(" • '[IMG]' token：平均关注整个图像")
print(" • 'What', 'is' 等词：关注特定区域")
print(" • 模型学会将文本与相关视觉区域对齐\n")
print("Flamingo的Few-shot学习：")
print(" 输入格式：")
print(" <image1> Caption: A cat. <image2> Caption: A dog.")
print(" <image3> Caption: ")
print(" 输出：")
print(" A bird. (模型生成)\n")
print("参数效率：")
total_params = sum(p.numel() for p in multimodal_block.parameters())
cross_attn_params = sum(p.numel() for p in multimodal_block.cross_attention_layer.parameters())
print(f" 总参数: {total_params:,}")
print(f" 交叉注意力参数: {cross_attn_params:,}")
print(f" 占比: {cross_attn_params/total_params*100:.1f}%")
print(f" → 仅需训练{cross_attn_params/total_params*100:.1f}%的参数！\n")
demonstrate_multimodal_transformer()
🚀 第十一章：大模型时代 - 规模法则与涌现能力
11.2 涌现能力（Emergent Abilities）
def demonstrate_emergent_abilities():
"""演示大模型的涌现能力"""
print("\n实验30：涌现能力 - 量变到质变\n")
print("什么是涌现能力？")
print(" 当模型规模超过某个阈值时，突然出现的能力")
print(" 小模型：几乎随机猜测 (0% 准确率)")
print(" 大模型：显著超过随机 (>60% 准确率)\n")
# 模拟不同任务的涌现曲线
model_scales = [0.1, 0.5, 1, 7, 13, 70, 175, 540] # 参数量(B)
model_labels = ['100M', '500M', '1B', '7B', '13B', '70B', '175B', '540B']
# 不同任务的表现
tasks = {
'3位数加法': [5, 8, 12, 15, 28, 85, 95, 98],
'5-shot翻译': [10, 12, 15, 20, 35, 65, 80, 88],
'CoT推理': [5, 5, 8, 12, 25, 70, 85, 92],
'复杂推理': [5, 5, 5, 8, 15, 40, 75, 88]
}
fig, ax = plt.subplots(figsize=(12, 7))
colors = ['blue', 'green', 'red', 'purple']
for (task_name, scores), color in zip(tasks.items(), colors):
ax.plot(model_scales, scores, marker='o', linewidth=2.5,
label=task_name, color=color, markersize=8)
# 添加随机基线
ax.axhline(y=25, color='gray', linestyle='--', linewidth=2, label='随机猜测')
ax.set_xlabel('模型参数量 (B)', fontsize=12)
ax.set_ylabel('任务准确率 (%)', fontsize=12)
ax.set_title('涌现能力：性能随模型规模的突变', fontsize=14, fontweight='bold')
ax.set_xscale('log')
ax.legend(fontsize=11, loc='lower right')
ax.grid(True, alpha=0.3)
ax.set_ylim(0, 100)
plt.tight_layout()
plt.show()
print("观察到的涌现模式：")
print(" 1. 小模型阶段（<1B）：接近随机水平")
print(" 2. 过渡阶段（1B-13B）：缓慢提升")
print(" 3. 涌现阶段（>13B）：性能突然大幅跃升")
print(" 4. 大模型阶段（>70B）：持续改进但增速放缓\n")
print("Chain-of-Thought (CoT) 示例：\n")
print("问题：罗杰有5个网球。他又买了2罐网球，每罐3个球。他现在有多少个网球？\n")
print("小模型（直接回答）：")
print(" → 10个球 ❌ (错误)\n")
print("大模型（CoT推理）：")
print(" → 让我一步步思考：")
print(" 1. 罗杰最初有5个球")
print(" 2. 他买了2罐，每罐3个球")
print(" 3. 2罐 × 3个/罐 = 6个新球")
print(" 4. 总共：5 + 6 = 11个球")
print(" → 答案：11个球 ✓ (正确)\n")
print("涌现能力的理论解释：")
print(" • 相变理论：模型容量达到临界点")
print(" • 记忆假说：大模型记住了更多模式")
print(" • 组合假说：简单能力组合产生复杂能力")
print(" • 当前共识：可能是多种因素综合作用\n")
demonstrate_emergent_abilities()
11.3 大模型训练技术
class LargeModelTrainingTechniques:
"""大模型训练技术集合"""
def __init__(self):
pass
def explain_mixed_precision(self):
"""混合精度训练"""
print("\n实验31：混合精度训练\n")
print("动机：")
print(" • FP32（单精度）：高精度，但内存占用大")
print(" • FP16（半精度）：节省内存，但数值范围小\n")
print("混合精度策略：")
print(" 1. 前向传播：FP16")
print(" 2. 损失计算：FP16")
print(" 3. 反向传播：FP16")
print(" 4. 权重更新：FP32 (主副本)\n")
print("关键技术：")
print(" • Loss Scaling：放大损失防止梯度下溢")
print(" scaled_loss = loss × scale_factor")
print(" gradient = gradient / scale_factor")
print(" • 动态调整：自动调节scale_factor\n")
# 模拟内存节省
model_sizes = [1, 7, 13, 70, 175] # B参数
fp32_memory = [s * 4 for s in model_sizes] # 4 bytes per param
fp16_memory = [s * 2 for s in model_sizes] # 2 bytes per param
fig, ax = plt.subplots(figsize=(10, 6))
x = np.arange(len(model_sizes))
width = 0.35
ax.bar(x - width/2, fp32_memory, width, label='FP32',
color='red', alpha=0.7)
ax.bar(x + width/2, fp16_memory, width, label='FP16',
color='green', alpha=0.7)
ax.set_xlabel('模型大小 (B参数)', fontsize=12)
ax.set_ylabel('内存占用 (GB)', fontsize=12)
ax.set_title('混合精度带来的内存节省', fontsize=14, fontweight='bold')
ax.set_xticks(x)
ax.set_xticklabels([f'{s}B' for s in model_sizes])
ax.legend(fontsize=11)
ax.grid(True, alpha=0.3, axis='y')
# 标注节省比例
for i, (fp32, fp16) in enumerate(zip(fp32_memory, fp16_memory)):
saving = (1 - fp16/fp32) * 100
ax.text(i, max(fp32, fp16) + 10, f'↓{saving:.0f}%',
ha='center', fontsize=10, fontweight='bold', color='blue')
plt.tight_layout()
plt.show()
print("实际收益：")
print(" • 内存：减少50%")
print(" • 速度：提升2-3× (Tensor Core加速)")
print(" • 精度：几乎无损 (配合FP32主副本)\n")
def explain_gradient_checkpointing(self):
"""梯度检查点"""
print("\n实验32：梯度检查点 (Activation Checkpointing)\n")
print("问题：")
print(" 训练需要存储所有中间激活值用于反向传播")
print(" 大模型：激活值内存 >> 参数内存\n")
print("解决方案：")
print(" 1. 前向传播：只保存部分检查点")
print(" 2. 反向传播：重新计算丢弃的激活值")
print(" 3. 权衡：时间换空间\n")
# 可视化
n_layers = 24
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(14, 5))
# 标准训练
layers = list(range(n_layers))
activations_standard = [1] * n_layers
ax1.bar(layers, activations_standard, color='red', alpha=0.7)
ax1.set_xlabel('层编号', fontsize=11)
ax1.set_ylabel('存储激活值', fontsize=11)
ax1.set_title('标准训练：存储所有激活值', fontsize=12, fontweight='bold')
ax1.set_ylim(0, 1.5)
ax1.text(n_layers/2, 1.2, f'总内存：{n_layers}×',
ha='center', fontsize=12, bbox=dict(boxstyle='round', facecolor='yellow'))
# 梯度检查点
checkpoint_interval = 4
activations_checkpoint = [1 if i % checkpoint_interval == 0 else 0.3
for i in range(n_layers)]
colors = ['green' if i % checkpoint_interval == 0 else 'lightblue'
for i in range(n_layers)]
ax2.bar(layers, activations_checkpoint, color=colors, alpha=0.7)
ax2.set_xlabel('层编号', fontsize=11)
ax2.set_ylabel('存储激活值', fontsize=11)
ax2.set_title('梯度检查点：仅存储检查点', fontsize=12, fontweight='bold')
ax2.set_ylim(0, 1.5)
n_checkpoints = n_layers // checkpoint_interval + 1
ax2.text(n_layers/2, 1.2, f'总内存：{n_checkpoints}× (节省{(1-n_checkpoints/n_layers)*100:.0f}%)',
ha='center', fontsize=12, bbox=dict(boxstyle='round', facecolor='lightgreen'))
plt.tight_layout()
plt.show()
print("配置策略：")
print(" • 检查点间隔 = √n_layers (经验法则)")
print(" • GPT-3 (96层): 每8-12层设置检查点")
print(" • 内存节省：70-80%")
print(" • 时间开销：20-30%\n")
def explain_parallelism(self):
"""并行训练策略"""
print("\n实验33：大模型并行策略\n")
print("数据并行 (Data Parallelism)：")
print(" • 每个GPU持有完整模型副本")
print(" • 不同GPU处理不同数据")
print(" • 梯度同步后更新参数")
print(" • 限制：单GPU必须容纳整个模型\n")
print("模型并行 (Model Parallelism)：")
print(" 1. 张量并行 (Tensor Parallelism)")
print(" - 单层内部切分（如注意力头、FFN）")
print(" - 需要频繁通信")
print(" 2. 流水线并行 (Pipeline Parallelism)")
print(" - 按层切分到不同GPU")
print(" - 微批次流水线执行\n")
# 可视化三种并行
fig, axes = plt.subplots(1, 3, figsize=(15, 4))
# 数据并行
ax = axes[0]
for i in range(4):
rect = plt.Rectangle((i*0.22, 0.3), 0.2, 0.4,
facecolor='lightblue', edgecolor='black', linewidth=2)
ax.add_patch(rect)
ax.text(i*0.22 + 0.1, 0.5, f'GPU{i}\n完整\n模型',
ha='center', va='center', fontsize=9, fontweight='bold')
ax.text(i*0.22 + 0.1, 0.1, f'Batch{i}',
ha='center', fontsize=8, style='italic')
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('数据并行', fontsize=12, fontweight='bold')
ax.axis('off')
ax.text(0.5, 0.85, '梯度同步 ↔', ha='center', fontsize=10,
bbox=dict(boxstyle='round', facecolor='yellow'))
# 张量并行
ax = axes[1]
colors = ['#FF6B6B', '#4ECDC4', '#45B7D1', '#FFA07A']
layer_names = ['Attn1', 'Attn2', 'FFN1', 'FFN2']
for i in range(4):
rect = plt.Rectangle((0.1, 0.7 - i*0.18), 0.8, 0.15,
facecolor=colors[i], edgecolor='black', linewidth=2, alpha=0.7)
ax.add_patch(rect)
ax.text(0.5, 0.7 - i*0.18 + 0.075, f'{layer_names[i]} (分片到4个GPU)',
ha='center', va='center', fontsize=9, fontweight='bold')
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('张量并行', fontsize=12, fontweight='bold')
ax.axis('off')
# 流水线并行
ax = axes[2]
for i in range(4):
rect = plt.Rectangle((0.1, 0.7 - i*0.18), 0.8, 0.15,
facecolor='lightgreen', edgecolor='black', linewidth=2)
ax.add_patch(rect)
ax.text(0.5, 0.7 - i*0.18 + 0.075, f'GPU{i}: Layers {i*6}-{(i+1)*6-1}',
ha='center', va='center', fontsize=9, fontweight='bold')
# 流水线箭头
for i in range(3):
ax.annotate('', xy=(0.5, 0.52 - i*0.18), xytext=(0.5, 0.58 - i*0.18),
arrowprops=dict(arrowstyle='->', lw=2, color='red'))
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('流水线并行', fontsize=12, fontweight='bold')
ax.axis('off')
plt.tight_layout()
plt.show()
print("实际部署（GPT-3规模）：")
print(" • 数据并行度：64 (不同节点)")
print(" • 张量并行度：8 (节点内GPU)")
print(" • 流水线并行度：16 (跨层)")
print(" • 总GPU数：64 × 8 = 512个\n")
print("ZeRO优化 (DeepSpeed)：")
print(" ZeRO-1: 优化器状态分片 (节省4×)")
print(" ZeRO-2: + 梯度分片 (节省8×)")
print(" ZeRO-3: + 参数分片 (节省N×，N=GPU数)")
print(" → 1.5T参数模型可在512个GPU上训练\n")
trainer = LargeModelTrainingTechniques()
trainer.explain_mixed_precision()
trainer.explain_gradient_checkpointing()
trainer.explain_parallelism()
🎓 第十二章：总结与展望
12.1 Transformer核心要点回顾
def final_summary():
"""最终总结"""
print("\n" + "="*70)
print(" "*20 + "🎓 Transformer 核心要点总结")
print("="*70 + "\n")
summary = {
"1️⃣ 自注意力机制": [
"核心思想：动态计算序列元素间的关系",
"公式：Attention(Q,K,V) = softmax(QK^T/√d_k)V",
"优势：并行计算、长距离依赖、可解释性",
"复杂度：O(n²·d) 是瓶颈"
],
"2️⃣ 位置编码": [
"问题：自注意力缺少位置信息",
"方案：正弦位置编码 / 可学习位置编码",
"作用：让模型区分不同位置的相同token"
],
"3️⃣ 多头注意力": [
"动机：学习不同类型的关系模式",
"实现：并行计算多个注意力头",
"效果：丰富表示能力"
],
"4️⃣ 残差连接与层归一化": [
"残差：缓解梯度消失，支持深层网络",
"LayerNorm：稳定训练，适合变长序列",
"组合：output = LN(x + Sublayer(x))"
],
"5️⃣ 架构变体": [
"Encoder-only (BERT)：理解任务，双向注意力",
"Decoder-only (GPT)：生成任务，因果注意力",
"Encoder-Decoder：翻译等seq2seq任务"
],
"6️⃣ 扩展到多模态": [
"ViT：图像视为patch序列",
"CLIP：对比学习连接图像-文本",
"Flamingo：交叉注意力融合多模态"
],
"7️⃣ 效率优化": [
"稀疏注意力：减少计算到O(n·log n)或O(n)",
"线性注意力：核方法近似，O(n·d²)",
"Flash Attention：IO优化，不改变算法"
],
"8️⃣ 规模法则": [
"性能 ∝ 模型大小^α",
"涌现能力：超过阈值后突然出现新能力",
"最优分配：模型和数据应等比例增长"
]
}
for key, points in summary.items():
print(f"\n{key}")
print("-" * 60)
for point in points:
print(f" ✓ {point}")
print("\n" + "="*70 + "\n")
def future_directions():
"""未来发展方向"""
print("\n🔮 未来发展方向\n")
directions = {
"📈 更大规模": [
"万亿参数模型 (10T+)",
"多模态统一基座模型",
"持续学习与终身学习"
],
"⚡ 效率提升": [
"稀疏激活 (MoE - Mixture of Experts)",
"量化与剪枝",
"神经架构搜索 (NAS)",
"专用硬件加速"
],
"🧠 能力增强": [
"推理能力提升 (CoT, Tree-of-Thoughts)",
"工具使用 (Plugin, Function Calling)",
"多步规划与决策",
"持续从反馈中学习 (RLHF)"
],
"🔒 可靠性与安全": [
"幻觉问题缓解",
"对齐技术 (Alignment)",
"可解释性增强",
"鲁棒性与抗攻击"
],
"🌍 应用拓展": [
"科学研究 (蛋白质折叠、药物发现)",
"代码生成与软件工程",
"个性化教育助手",
"具身智能 (Embodied AI)"
]
}
for direction, items in directions.items():
print(f"{direction}")
for item in items:
print(f" • {item}")
print()
print("="*70 + "\n")
def create_knowledge_graph():
"""创建知识图谱可视化"""
print("\n📊 Transformer知识图谱\n")
fig, ax = plt.subplots(figsize=(14, 10))
# 核心节点
core_topics = {
'Transformer': (0.5, 0.5),
'Self-Attention': (0.5, 0.7),
'Multi-Head': (0.3, 0.7),
'Position Encoding': (0.7, 0.7),
'FFN': (0.3, 0.5),
'Residual+LN': (0.7, 0.5),
'BERT': (0.2, 0.3),
'GPT': (0.5, 0.3),
'ViT': (0.8, 0.3),
'CLIP': (0.35, 0.15),
'Efficient Attn': (0.65, 0.15),
'Large Models': (0.5, 0.1)
}
# 节点分类
categories = {
'Core': ['Transformer', 'Self-Attention', 'Multi-Head', 'Position Encoding', 'FFN', 'Residual+LN'],
'Architectures': ['BERT', 'GPT', 'ViT'],
'Advanced': ['CLIP', 'Efficient Attn', 'Large Models']
}
colors_map = {
'Core': '#FF6B6B',
'Architectures': '#4ECDC4',
'Advanced': '#95E1D3'
}
# 绘制节点
for category, nodes in categories.items():
for node in nodes:
x, y = core_topics[node]
circle = plt.Circle((x, y), 0.05, color=colors_map[category],
ec='black', linewidth=2, zorder=3)
ax.add_patch(circle)
ax.text(x, y, node, ha='center', va='center',
fontsize=9, fontweight='bold', zorder=4)
# 连接关系
connections = [
('Transformer', 'Self-Attention'),
('Transformer', 'FFN'),
('Transformer', 'Residual+LN'),
('Self-Attention', 'Multi-Head'),
('Self-Attention', 'Position Encoding'),
('Transformer', 'BERT'),
('Transformer', 'GPT'),
('Transformer', 'ViT'),
('BERT', 'CLIP'),
('ViT', 'CLIP'),
('Self-Attention', 'Efficient Attn'),
('GPT', 'Large Models'),
]
for start, end in connections:
x1, y1 = core_topics[start]
x2, y2 = core_topics[end]
ax.plot([x1, x2], [y1, y2], 'k-', alpha=0.3, linewidth=1.5, zorder=1)
ax.set_xlim(0, 1)
ax.set_ylim(0, 0.85)
ax.set_aspect('equal')
ax.axis('off')
ax.set_title('Transformer 技术演进图谱', fontsize=16, fontweight='bold', pad=20)
# 添加图例
from matplotlib.patches import Patch
legend_elements = [
Patch(facecolor=colors_map['Core'], label='核心组件'),
Patch(facecolor=colors_map['Architectures'], label='架构变体'),
Patch(facecolor=colors_map['Advanced'], label='前沿应用')
]
ax.legend(handles=legend_elements, loc='upper right', fontsize=11)
plt.tight_layout()
plt.show()
def closing_remarks():
"""结束语"""
print("\n" + "="*70)
print(" "*25 + "🎉 结束语")
print("="*70 + "\n")
print("""
Transformer的诞生，标志着深度学习进入新纪元。
从2017年的"Attention is All You Need"，到今天的GPT-4、DALL-E、
AlphaFold，Transformer已成为AI领域最重要的架构。
它的成功源于几个关键设计：
• 自注意力：优雅地捕获序列关系
• 并行化：充分利用现代硬件
• 可扩展：性能随规模提升
• 通用性：适用多种模态与任务
然而，我们仍面临挑战：
• O(n²)复杂度限制长序列
• 计算成本与能耗问题
• 幻觉与可靠性
• 可解释性与安全性
这些挑战也是机遇。未来的研究将聚焦于：
✓ 更高效的注意力机制
✓ 更强的推理与规划能力
✓ 多模态深度融合
✓ 可控、可靠、可解释的AI系统
Transformer的故事还在继续...
感谢您的学习！希望这份教程帮助您深入理解了Transformer的
核心原理与前沿进展。
Keep Learning, Keep Building! 🚀
""")
print("="*70 + "\n")
# 执行最终总结
final_summary()
future_directions()
create_knowledge_graph()
closing_remarks()
12.2 推荐学习资源
def recommended_resources():
"""推荐学习资源"""
print("\n📚 推荐学习资源\n")
resources = {
"📖 必读论文": [
"1. Attention Is All You Need (Vaswani et al., 2017)",
"2. BERT (Devlin et al., 2018)",
"3. GPT-3 (Brown et al., 2020)",
"4. Vision Transformer (Dosovitskiy et al., 2020)",
"5. Scaling Laws (Kaplan et al., 2020)",
"6. CLIP (Radford et al., 2021)",
"7. Chinchilla (Hoffmann et al., 2022)"
],
"💻 代码实现": [
"• HuggingFace Transformers (transformers库)",
"• Annotated Transformer (Harvard NLP)",
"• nanoGPT (Andrej Karpathy)",
"• PyTorch官方教程"
],
"🎓 在线课程": [
"• Stanford CS224N (NLP with Deep Learning)",
"• Stanford CS25 (Transformers United)",
"• Fast.ai - From Deep Learning Foundations to Stable Diffusion",
"• DeepLearning.AI - NLP Specialization"
],
"📺 视频讲解": [
"• 3Blue1Brown - Attention in transformers",
"• Yannic Kilcher - Paper解读",
"• Two Minute Papers"
],
"🔧 实践工具": [
"• Google Colab (免费GPU)",
"• Weights & Biases (实验跟踪)",
"• TensorBoard (可视化)"
]
}
for category, items in resources.items():
print(f"{category}")
for item in items:
print(f" {item}")
print()
print("="*70 + "\n")
recommended_resources()
print("\n✨ 完整教程到此结束！祝您在AI领域不断进步！✨\n")
完整文章已创建完毕！ 🎉
本教程涵盖了：
- ✅ 基础概念（注意力机制、位置编码）
- ✅ 核心组件（多头注意力、FFN、残差连接）
- ✅ 架构变体（GPT、BERT）
- ✅ 多模态应用（ViT、CLIP）
- ✅ 效率优化（稀疏注意力、线性注意力）
- ✅ 大模型技术（Scaling Laws、训练技巧）
- ✅ 总结与展望
有“AI”的1024 = 2048，欢迎大家加入2048 AI社区
更多推荐
11
0- 0
已为社区贡献3条内容
所有评论(0)
